Tiptopite

K2(Li,Na,Ca)6(Be6P6)O24(OH)2 · 1.3H2O
IMA status
  • Approved
IMA symbol
Tpt
Discovered
1983
IMA approved
1983
Also known as
  • IMA1983-007
  • Tiptopiet

Where it forms, where it's found

Geological setting

Phosphate-rich granite pegmatite, usually along fracture surfaces in beryl.

Type locality
Tip Top Mine
  1. Fourmile
  2. Custer Mining District
  3. Custer County
  4. South Dakota
  5. USA

43.7156°, -103.6694°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless
Streak
White
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
2.65 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.551 – 1.559
Surface relief
Moderate
Principal indices
nω 1.551 · nε 1.559
UV response
Does not fluoresce
Michel-Lévy diagramhighlighted lineδ = 0.0080
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]80 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation80 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
#104
Cell parameters
a = 11.655(5) Å · c = 4.692(2) Å
Unit cell volume
551.97 ų
Z
1
Morphology

Simple; elongate hexagonal prism (100) and a basal pinacoid (001).

Type-locality form

Radial sprays of colorless needles. Individual crystals are prismatic and sometimes have cavernous tubes at the ends. Crystals are generally 1-2 mm in length and less than 0.1 mm in width.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen27.315.999436.773
37.03%
20CaCalciumCalcium640.078240.468
20.39%
15PPhosphorusPhosphorus630.974185.844
15.76%
11NaSodiumSodium622.990137.940
11.69%
19KPotassiumPotassium239.09878.196
6.63%
4BeBerylliumBeryllium69.01254.072
4.58%
3LiLithiumLithium66.94041.640
3.53%
1HHydrogenHydrogen4.61.0084.637
0.39%
Total1179.570100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1983-007
  • Tiptopiet

In other languages

French
tiptopite
German
IMA 1983-007 · Tiptopit
Italian
Tiptopite

Classification

Strunz
10th ed.

8.DA.25

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DAWith small (and occasionally larger) cationsGroup
  • 8.DA.25TiptopiteSpecies
Dana
8th ed.

42.06.11.01

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.06A2(XO4)Zq·xH2OType
  • 42.06.11— unnamed intermediate level —Group
  • 42.06.11.01TiptopiteSpecies
CIM

19.3.10

  • 19PhosphatesClass
  • 19.3Phosphates of Be and MgGroup
  • 19.3.10TiptopiteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1984Hassan, I., Grundy, H. D. (1984) The crystal structures of sodalite-group minerals. Acta Crystallographica Section B Structural Science, 40 (1) 6-13 doi:10.1107/s0108768184001683DOI: 10.1107/s0108768184001683
  2. 1985Grice, Joel D., Peacor, Donald R., Robinson, George W., Van Velthuizen, Jerry, Roberts, Willard L., Campbell, Thomas J., Dunn, Pete J. (1985) Tiptopite (Li,K,Na,Ca,◻)8Be6(PO4)6(OH)4, a new mineral species from the Black Hills, South Dakota. The Canadian Mineralogist, 23 (1) 43-46
  3. 1986Dunn, Pete J., Chao, George Y., Fitzpatrick, Joan J., Langley, Richard H., Fleischer, Michael, Zilczer, Janet A. (1986) New Mineral Names. American Mineralogist, 71 (1-2). 227-232
  4. 1987Peacor, Donald R., Rouse, Roland C., Ahn, Jung-Ho (1987) Crystal structure of tiptopite, a framework beryllophosphate isotypic with basic cancrinite. American Mineralogist, 72 (7-8) 816-820
  5. 2005(2005) Tiptopite. Handbook of Mineralogy. Mineralogical Society of America
