Trabzonite

Ca4[Si3O9(OH)](OH)
IMA status
  • Approved
IMA symbol
Trb
Discovered
1983
IMA approved
1983
Also known as
  • IMA1983-071a
  • Trabzoniet

Where it forms, where it's found

Geological setting

Retrograde skarn.

Type locality
Güneyce-Ikizdere
  1. Rize Province
  2. Turkey
3recorded occurrences
Source · OpenStreetMap

Physical

Transparency
Transparent
Colour
Colourless
Streak
White
Cleavage
None Observed
Fracture
Conchoidal
Density
2.9 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 55 – 60° · 2V calc = 62°
Refractive index
1.632 – 1.64
Surface relief
Moderate
Principal indices
nα 1.632 · nβ 1.634 · nγ 1.64
Dispersion
weak to distinct
Michel-Lévy diagramhighlighted lineδ = 0.0080
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]80 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation80 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#18
Cell parameters
a = 20.6 Å · b = 9.1 Å · c = 10.3 Å
Cell angles
β = 98 °
Ratio a:b:c
1 : 0.442 : 0.500
Z
8
Type-locality form

Irregular grains to 0.2 mm.

Comment

Originally assumed to be P21/m.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1115.999175.989
41.65%
20CaCalciumCalcium440.078160.312
37.94%
14SiSiliconSilicon328.08584.255
19.94%
1HHydrogenHydrogen21.0082.016
0.47%
Total422.572100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Mn
  • Mg
  • Na

Synonyms

  • IMA1983-071a
  • Trabzoniet

In other languages

German
IMA 1983-071a · Trabzonit
Italian
Trabzonite

Classification

Strunz
10th ed.

9.BJ.15

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BJSorosilicates with Si3O10, Si4O11, etc. anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BJ.15TrabzoniteSpecies
Dana
8th ed.

57.01.03.01

  • 57Sorosilicates Si3o10 Groups and Larger Noncyclic GroupsClass
  • 57.01Insular Si3O10 and Larger Noncyclic Groups with [Si3O10] groupsType
  • 57.01.03— unnamed intermediate level —Group
  • 57.01.03.01TrabzoniteSpecies
CIM

14.5.20

  • 14Silicates not Containing AluminumClass
  • 14.5Silicates of CaGroup
  • 14.5.20TrabzoniteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1986Sarp, H., Burri, G. (1986) Trabzonite Ca4Si3O10·2H2O a new hydrated calcium silicate. Schweizerische Mineralogische und Petrographische Mitteilungen: 66: 453-453.
  2. 1987Sarp H, Burri G (1987) Yeni bir mineral, trabzonit, Ca4 Si3 O10 2H2O. Bulletin of the Geological Society of Turkey 30, 57-60
  3. 1988Jambor, John L., Ercit, Ernst A. J. Burke T. Scott, Grice, Joel D. (1988) New Mineral Names. American Mineralogist, 73 (11-12) 1492-1499
  4. 2001(2001) Trabzonite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2011Armbruster, T., Lazic, B., Gfeller, F., Galuskin, E. V., Galuskina, I. O., Savelyeva, V. B., Zadov, A. E., Pertsev, N. N., Dzierżanowski, P. (2011) Chlorine content and crystal chemistry of dellaite from the Birkhin gabbro massif, Eastern Siberia, Russia. Mineralogical Magazine, 75 (2) 379-394 doi:10.1180/minmag.2011.075.2.379 DOI: 10.1180/minmag.2011.075.2.379
