Tschermakite

◻Ca2(Mg3Al2)(Si6Al2)O22(OH)2
IMA status
  • Approved
IMA symbol
Tsr
Discovered
1945
Also known as
  • Aluminotschermakite
  • Tschermakitic hornblende

Where it forms, where it's found

Geological setting

Eclogites and other ultramafic rocks, amphibolites or other medium to high grade metamorphic rocks.

92recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
Medium green to dark green to green-black to black · brown (rare).
Streak
Pale grey-green
Tenacity
brittle
Cleavage
Perfect

on (110)

Density
3.15 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 60 – 90°
Refractive index
1.623 – 1.688
Surface relief
High
Principal indices
nα 1.623 – 1.660 · nβ 1.630 – 1.680 · nγ 1.638 – 1.688
Pleochroism
Visible

In browns and greens

Dispersion
r > v strong
Luminescence
Nonfluorescent
Michel-Lévy diagramhighlighted lineδ = 0.0215
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]215 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation215 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 9.762(6) Å · b = 17.994(12) Å · c = 5.325(6) Å
Cell angles
β = 105.10(8) °
Ratio a:b:c
1 : 1.843 : 0.545
Z
2
Morphology

Prismatic crystals, reaction rims on other minerals.

Twinning

single or multiple parallel to (100)

Parting
on (100)(001)
Crystal structure

Chemical composition

Impurities
  • Ti
  • Mn
  • Na
  • K
  • H2O
  • Fe

Synonyms

  • Aluminotschermakite
  • Tschermakitic hornblende

In other languages

French
Tschermakite
German
Tschermakit
Spanish
Tschermakita
Italian
tschermakite
Chinese
镁钙闪石 · 镁钠铁闪石

Classification

Strunz
10th ed.

9.DE.10

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DEInosilicates with 2-periodic double chains, Si4O11; ClinoamphibolesGroup
  • 9.DE.10TschermakiteSpecies
CIM

16.11.4

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.11Aluminosilicates of Ca and Mg with or without alkalisGroup
  • 16.11.4TschermakiteSpecies

Group, growth & confusion

In the same group
1 members
Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1945Winchell, A.N. (1945) Variations in composition and properties of calciferous amphiboles. American Mineralogist: 30:27-50
  2. 1945American Journal of Science (1945): 243: 29.
  3. 1989Phillips, Michael W., Draheim, James E., Popp, Robert K., Clowe, Celia A., Pinkerton, A. Alan (1989) Effects of oxidation-dehydrogenation in tschermakitic hornblende. American Mineralogist, 74 (7-8) 764-773
  4. 1998Mandarino, Joseph A. (1998) The Second List of Additions and Corrections to the Glossary of Mineral Species (1995) - The Amphibole Group. The Mineralogical Record, 29 (3) 169-174
  5. 2001(2001) Tschermakite. Handbook of Mineralogy. Mineralogical Society of America
