Umbite

K2ZrSi3O9 · H2O
IMA status
  • Approved
IMA symbol
Umb
Discovered
1982
IMA approved
1982
Also known as
  • IMA1982-006
  • Umbiet

Where it forms, where it's found

Type locality
Vuonnemiok River Valley
  1. Murmansk Oblast
  2. Russia

67.5819°, 34.1894°

8recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Translucent
Colour
Colourless · light yellow
Cleavage
Perfect

On (010), perfect, micaceous; (100), less perfect

Density
2.79 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 80° · 2V calc = 68°
Refractive index
1.596 – 1.63
Surface relief
Moderate
Principal indices
nα 1.596 · nβ 1.619 · nγ 1.63
Dispersion
r < v weak
Extinction
X = c; Y = b; Z = a.
UV response
Weak yellowish fluorescence under UV. Fluorescence is bright whitish-green at the temperature of liquid nitrogen.
Michel-Lévy diagramhighlighted lineδ = 0.0340
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]340 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation340 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#44
Cell parameters
a = 10.208(2) Å · b = 13.241(4) Å · c = 7.174(1) Å
Ratio a:b:c
1 : 1.297 : 0.703
Z
4
Morphology

Platy crystals, flattened on (010} with the forms (010) (dominant) and (101), (110), and (001).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1015.999159.990
38.49%
40ZrZirconiumZirconium191.22491.224
21.95%
14SiSiliconSilicon328.08584.255
20.27%
19KPotassiumPotassium239.09878.196
18.81%
1HHydrogenHydrogen21.0082.016
0.48%
Total415.681100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Hf
  • Fe
  • Na
  • F

Synonyms

  • IMA1982-006
  • Umbiet

In other languages

German
IMA 1982-006 · Umbit
Italian
Umbite
Russian
Умбит
Arabic
أمبايت · أمبيت

Classification

Strunz
10th ed.

9.DG.25

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DGInosilicates with 3-periodic single and multiple chainsGroup
  • 9.DG.25UmbiteSpecies
Dana
8th ed.

59.02.01.01

  • 59Cyclosilicates Three-membered RingsClass
  • 59.02Three-Membered Rings, hydratedType
  • 59.02.01Umbite and related speciesGroup
  • 59.02.01.01UmbiteSpecies
CIM

14.10.16

  • 14Silicates not Containing AluminumClass
  • 14.10Silicates of Zr or HfGroup
  • 14.10.16UmbiteSpecies

Group, growth & confusion

In the same group
1 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. European Journal of Solid State Inorganic Chemistry: 34: 381-390.
  2. 1983Khomyakov, A.P., Voronkov, A.A., Kobyashev, Y.S., Polezhaeva, L.I. (1983) Umbite and paraumbite, new potassium zirconosilicates from the Khibina alkalic massif. Zapiski Vserossiyskogo Mineralogicheskogo Obshchestva, 112. 461-469.
  3. 1984Dunn, Pete J., Fleischer, Michael, Francis, Carl A., Langley, Richard H., Kissin, Stephen A., Shigley, Hames E., Vanko, David A., Zilczer, Janet A. (1984) New mineral names. American Mineralogist, 69 (7-8) 810-815
  4. 1993Ilyushin, G.D. (1993) New data on the crystal structure of umbite K2ZrSi3O9·H2O. Neorganicheskie Materialy, 29, 971-975.
  5. 2001(2001) Umbite. Handbook of Mineralogy. Mineralogical Society of America
