Vigezzite

CaNb2O6
IMA status
  • Approved
IMA symbol
Vgz
Discovered
1977
IMA approved
1977
Also known as
  • IMA1977-008
  • Vigezziet
  • Viggesite

Where it forms, where it's found

Geological setting

In cavities of an albitic rock.

Type locality
Alpe Rosso
  1. Orcesco
  2. Druogno
  3. Verbano-Cusio-Ossola Province
  4. Piedmont
  5. Italy

46.1289°, 8.4139°

15recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Orange-yellow
Streak
White
Tenacity
very brittle
Cleavage
Distinct/Good

(010), distinct

Fracture
Conchoidal
Density
5.54 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
2.14 – 2.315
Surface relief
Very high
Principal indices
nα 2.14 · nγ 2.315
Dispersion
extreme
Extinction
X = a; Y = b; Z = c.
UV response
Not fluorescent with SW or LW UV, however, a quartz-lamp produces a brilliant green fluorescence, characteristic of cerium-bearing minerals.
Michel-Lévy diagramhighlighted lineδ = 0.1750
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1750 nm4th order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1750 nm
Order4th order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#71
Cell parameters
a = 7.55 Å · b = 11.03 Å · c = 5.36 Å
Ratio a:b:c
1 : 1.461 : 0.710
Z
4
Morphology

Euhedral, flattened prismatic crystals, strongly striated on (010) parallel to prism axis. The prisms are terminated only by the pinacoid (100).

Type-locality form

Euhedral, flat prismatic crystals up to 2-3 mm in length.

Comment

Space group Pnmb (non-standard setting).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
41NbNiobiumNiobium292.906185.812
57.73%
8OOxygenOxygen615.99995.994
29.82%
20CaCalciumCalcium140.07840.078
12.45%
Total321.884100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ta

Synonyms

  • IMA1977-008
  • Vigezziet
  • Viggesite

In other languages

German
IMA 1977-008 · Vigezzit
Spanish
Vigezzita
Italian
Vigezzite

Classification

Strunz
10th ed.

4.DF.05

  • 4OxidesClass
  • 4.DMetal: Oxygen = 1:2 and similarDivision
  • 4.DFWith large (+- medium-sized) cations; dimers and trimers of edgesharing octahedraGroup
  • 4.DF.05VigezziteSpecies
Dana
8th ed.

08.03.07.01

  • 08Multiple Oxides Containing Niobium, Tantalum or TitaniumClass
  • 08.03AB2O6Type
  • 08.03.07— unnamed intermediate level —Group
  • 08.03.07.01VigezziteSpecies
CIM

18.2.19

  • 18Niobates and TantalatesClass
  • 18.2Niobates and tantalates containing rare earths but not UGroup
  • 18.2.19VigezziteSpecies

Group, growth & confusion

In the same group
7 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1979Mattioli, V. (1979) La vigezzite, nuovo minerale. Rivista Mineralogica Italiana: 1979: 5-13.
  2. 1979Graeser, S., Schwander, H., Hänni, H., Mattioli, V. (1979) Vigezzite, (Ca, Ce) (Nb, Ta,Ti)2O6, a new aeschynite-type mineral from the Alps. Mineralogical Magazine, 43 (328) 459-462 doi:10.1180/minmag.1979.043.328.02 DOI: 10.1180/minmag.1979.043.328.02
  3. 1980Fleischer, M., Cabri, L.J., Chao, G.Y., Pabst, A. (1980) New minerals names. American Mineralogist: 65: 811-812.
  4. 1983Mattioli, Vittorio (1983) Fersmit und Vigezzit. Zwei seltene Minerale von Orcesco im Val Vigezzo [Fersmite and Vigezzite. Two rare minerals from Orcesco in Val Vigezzo]. Lapis, 8 (2) 22-24
  5. 1987Mattioli, V. (1987) Novità mineralogiche in Val d'Ossola. Rivista Italiana di Paleontologia e Stratigrafia: 10: 1-11.
