Fersmite

CaNb2O6
IMA status
  • Approved
  • Grandfathered
IMA symbol
Fsm
Discovered
1946
Also known as
  • Fersmiet

Where it forms, where it's found

Geological setting

accessory mineral in nepheline syenites and carbonatites.

Type locality
Vein No. 37A
  1. Buldym Lake
  2. Vishnevye Mountains
  3. Chelyabinsk Oblast
  4. Russia
110recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104 – 4.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent · Opaque
Colour
Black · dark brown · lemon-yellow to yellow-brown
Streak
Grayish brown
Tenacity
very brittle
Cleavage
Distinct/Good

(100)

Fracture
Sub-Conchoidal
Density
4.78 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 20 – 25° · 2V calc = 36°
Refractive index
2.07 – 2.19
Surface relief
Very high
Principal indices
nα 2.07 · nβ 2.08 · nγ 2.19
Pleochroism
Weak

X = Y = pale greenish yellow to colorless; Z = dark greenish yellow to olive-yellow

Dispersion
r < v strong
UV response
Fluoresces yellow-green to bluish green under SW and LW UV; light blue cathodoluminescence
Michel-Lévy diagramhighlighted lineδ = 0.1200
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1200 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1200 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#63
Cell parameters
a = 14.926(4) Å · b = 5.752(4) Å · c = 5.204(4) Å
Ratio a:b:c
1 : 0.385 : 0.349
Z
4
Morphology

prismatic crystals

Parting
present
Comment

commonly metamict

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
41NbNiobiumNiobium292.906185.812
57.73%
8OOxygenOxygen615.99995.994
29.82%
20CaCalciumCalcium140.07840.078
12.45%
Total321.884100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Fersmiet

In other languages

German
Fersmit
Spanish
Fersmita
Italian
Fersmite
Chinese
铌钙矿
Russian
Ферсмит

Classification

Strunz
10th ed.

4.DG.05

  • 4OxidesClass
  • 4.DMetal: Oxygen = 1:2 and similarDivision
  • 4.DGWith large (+- medium-sized) cations; chains of edge-sharing octahedraGroup
  • 4.DG.05FersmiteSpecies
Dana
8th ed.

08.03.03.01

  • 08Multiple Oxides Containing Niobium, Tantalum or TitaniumClass
  • 08.03AB2O6Type
  • 08.03.03— unnamed intermediate level —Group
  • 08.03.03.01FersmiteSpecies
CIM

18.2.12

  • 18Niobates and TantalatesClass
  • 18.2Niobates and tantalates containing rare earths but not UGroup
  • 18.2.12FersmiteSpecies

Group, growth & confusion

In the same group
6 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1946Bohnstedt-Kupletskaya, E.M., Burova, T.A. (1946) Fersmite, a new calcium niobate from the pegmatites of the Vishnevye Mts., the Central Urals. Comptes Rendus (Doklady) de l’Académie des Sciences de l’URSS: 52: 69-71.
  2. 1947Fleischer, M. (1947) New mineral names. American Mineralogist, 32 (5-6). 371-374
  3. 1958Ismailzade, I.G. (1958) Crystal structure of the niobiates and the tantalates of bivalent metals and their solid solutions. Crystallography Reports 22: 1480-1482.
  4. 1993Yamnova, N.A., Tsomirova, E.S., Leonyuk, N.I. (1993) Crystal structure of synthetic La-containing fersmite. Crystallography Reports: 38: 124-125.
  5. 2001Gurbanova, O.A., Rastsvetaeva, R.K., Kashaev, A.A., Smolin, A.S. (2001) Refined crystal structure of TR-fersmite (TR = Ce). Crystallography Reports: 46: 194-195.
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Fersmite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/fersmite-1539},
  note      = {Accessed 2026-05-11}
}
