Wallkilldellite

Ca2Mn2+3(AsO4)2(OH)4 · 9H2O
IMA status
  • Approved
IMA symbol
Wlk
Discovered
1982
IMA approved
1982
Also known as
  • IMA1982-084
  • Wallkilldelliet
  • Wallkilldellite-(Mn)

Where it forms, where it's found

Geological setting

Massive, granular, franklinite/willemite ore with abundant calcite.

Type locality
Sterling Mine
  1. Sterling Hill
  2. Ogdensburg
  3. Sussex County
  4. New Jersey
  5. USA

41.0836°, -74.6047°

23recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Dark red to nearly black
Streak
Pale orange
Cleavage
Perfect

(0001)

Density
2.85 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.728
Surface relief
High
Principal indices
nω 1.728
Pleochroism
Weak

O = reddish orange; E = pale pinkish orange

UV response
Not fluorescent in UV

Crystallography

Crystal system
Hexagonal
Cell parameters
a = 6.506(7) Å · c = 23.49(3) Å
Z
1
Type-locality form

Flattened, radial clusters of platy crystals without obvious morphological characteristics other than the extremely platy habit. Crystal size is approximately 0.1 mm and aggregates to 0.5 mm.

Comment

Point Group: 6/m 2/m 2/m, _6 m2, or 6mm.: Space Group: P63/mmc, P_6 2c, or P63mc.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2115.999335.979
44.62%
25MnManganeseManganese354.938164.814
21.89%
33AsArsenicArsenic274.922149.844
19.90%
20CaCalciumCalcium240.07880.156
10.65%
1HHydrogenHydrogen221.00822.176
2.94%
Total752.969100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1982-084
  • Wallkilldelliet
  • Wallkilldellite-(Mn)

In other languages

German
IMA 1982-084 · Wallkilldellit
Italian
Wallkilldellite

Classification

Strunz
10th ed.

8.DL.20

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DLWith large and medium-sized cations, (OH, etc.):RO4 = 2:1Group
  • 8.DL.20WallkilldelliteSpecies
CIM

20.8.16

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.8Arsenates of MnGroup
  • 20.8.16WallkilldelliteSpecies

Group, growth & confusion

Often grow together
1 mineral
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1983Dunn, Pete J., Peacor, Donald R. (1983) Kittatinnyite and wallkilldellite, silicate/arsenate analogues containing calcium and manganese, from Franklin and Sterling Hill, New Jersey. American Mineralogist, 68 (9-10) 1029-1032
  2. 2021(2021) Wallkilldellite. Handbook of Mineralogy. Mineralogical Society of America
