Yusupovite

Na2Zr(Si6O15)(H2O)3
IMA status
  • Approved
IMA symbol
Ypv
IMA approved
2014
Also known as
  • IMA2014-022
  • Yusupoviet

Where it forms, where it's found

Geological setting

Yusupovite was found in rock samples from the Upper DaraiPioz alkaline massif in pegmatite

Type locality
Dara-i-Pioz Massif
  1. Districts of Republican Subordination
  2. Tajikistan

39.4504°, 70.7163°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
colorless
Streak
white
Tenacity
brittle
Cleavage
Perfect

(110)

Fracture
Splintery
Density
2.69 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 42° · 2V calc = 45°
Refractive index
1.563 – 1.577
Surface relief
Moderate
Principal indices
nα 1.563 · nβ 1.565 · nγ 1.577
Dispersion
strong: r > v
Michel-Lévy diagramhighlighted lineδ = 0.0140
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]140 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation140 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 14.5975(4) Å · b = 14.1100(4) Å · c = 14.4394(4) Å
Cell angles
β = 90.0399(4) °
Ratio a:b:c
1 : 0.967 : 0.989
Z
8
Type-locality form

Prismatic grains about 2 mm in size embedded in reedmergnerite

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1815.999287.982
48.02%
14SiSiliconSilicon628.085168.510
28.10%
40ZrZirconiumZirconium191.22491.224
15.21%
11NaSodiumSodium222.99045.980
7.66%
1HHydrogenHydrogen61.0086.048
1.01%
Total599.744100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2014-022
  • Yusupoviet

In other languages

German
IMA 2014-022 · Yusupovit
Italian
yusupovite
Russian
юсуповит

Classification

Strunz
10th ed.

9.DG.70

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DGInosilicates with 3-periodic single and multiple chainsGroup
  • 9.DG.70YusupoviteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 2014Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2014) New minerals and nomenclature modifications approved in 2014, CNMNC Newsletter No 21. Mineralogical Magazine, 78 (4) 797-804 doi:10.1180/minmag.2014.078.4.03DOI: 10.1180/minmag.2014.078.4.03
  2. 2015Agakhanov, Atali A., Pautov, Leonid A., Karpenko, Vladimir Y., Sokolova, Elena, Abdu, Yassir A., Hawthorne, Frank C., Pekov, Igor V., Siidra, Oleg I. (2015) Yusupovite, Na2Zr(Si6O15)(H2O)3, a new mineral species from the Darai-Pioz alkaline massif and its implications as a new microporous filter for large ions. American Mineralogist, 100 (7) 1502-1508 doi:10.2138/am-2015-5092 DOI: 10.2138/am-2015-5092
  3. 2017(2017) Yusupovite. Handbook of Mineralogy. Mineralogical Society of America
