Elpidite

Na2ZrSi6O15 · 3H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Epd
Discovered
1894
Also known as
  • Elpidiet

Where it forms, where it's found

Type locality
Narssârssuk pegmatite
  1. Narsaarsuk Plateau
  2. Igaliku
  3. Kujalleq
  4. Greenland

61.0331°, -45.3778°

57recorded occurrences
Source · OpenStreetMap

Varieties

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent · Opaque
Colour
Colorless · white · gray · yellowish · orange · brown · beige
Cleavage
Perfect

On (110)

Fracture
Splintery
Density
2.52 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
1.56 – 1.574
Surface relief
Moderate
Principal indices
nα 1.56 · nβ 1.565 – 1.569 · nγ 1.574
Dispersion
r < v moderate
Extinction
X = c; Y = b; Z = a.
Michel-Lévy diagramhighlighted lineδ = 0.0140
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]140 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation140 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 7.29 Å · b = 14.3 Å · c = 7.03 Å
Ratio a:b:c
1 : 1.962 : 0.964
Comment

Space group of the hydrated (H3O)-bearing) variety is Pma2

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1815.999287.982
48.02%
14SiSiliconSilicon628.085168.510
28.10%
40ZrZirconiumZirconium191.22491.224
15.21%
11NaSodiumSodium222.99045.980
7.66%
1HHydrogenHydrogen61.0086.048
1.01%
Total599.744100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Nb
  • Ca
  • K
  • F
  • Cl

Synonyms

  • Elpidiet

In other languages

French
elpidite
German
Elpidit
Italian
Elpidite

Classification

Strunz
10th ed.

9.DG.65

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DGInosilicates with 3-periodic single and multiple chainsGroup
  • 9.DG.65ElpiditeSpecies
Dana
8th ed.

72.05.04.02

  • 72Phyllosilicates Two-dimensional Infinite Sheets with Other Than Six-membered RingsClass
  • 72.05Two-Dimensional Infinite Sheets with Other Than Six-Membered Rings with corrugated and complex layersType
  • 72.05.04Elpidite/armstrongiteGroup
  • 72.05.04.02ElpiditeSpecies
CIM

14.10.9

  • 14Silicates not Containing AluminumClass
  • 14.10Silicates of Zr or HfGroup
  • 14.10.9ElpiditeSpecies

Group, growth & confusion

Often grow together
1 mineral
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1894Lindström, G. (1894) Elpidit, ett nytt mineral från Igaliko, Geologiska Föreningens i Stockholm Förhandlingar, 16, 330-335.
  2. 1964Neronova, N.N., Belov, N.V. (1964) Crystal structure of elpidite, Na2Zr[Si6O15]·3H2O. Soviet Physics - Crystallography: 9: 700-705.
  3. 1967Chao, G. Y. (1967) Leucophanite, elpidite, and narsarsukite from the Desourdy quarry, Mont St. Hilaire, Quebec. The Canadian Mineralogist, 9 (2) 286-287
  4. 1973Cannillo, Elio, Rossi, Guiseppe, Ungaretti, Luciano (1973) The crystal structure of elpidite. American Mineralogist, 58 (1-2) 106-109
  5. 1978Sapozhnikov, A.N., Kashaev, A.A. (1978) Features of the crystal structure of calcium-containing elpidite. Kristallografiya (Sov. Phys. Crystal.): 23: 52-65. (in Russian)
