Zinconigerite-6N6S

Zn3Sn2Al16O30(OH)2
IMA status
  • Approved
IMA symbol
Zng-6N6S
Also known as
  • IMA2018-122a
  • Zinconigeriet-6N6S

Where it forms, where it's found

Geological setting

Skarn.

Type locality
Xianghualing Sn-polymetallic ore field
  1. Linwu Co.
  2. Chenzhou
  3. Hunan
  4. China

25.4667°, 112.5667°

3recorded occurrences
Source · OpenStreetMap

Physical

Density
4.438 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.85 – 1.87
Surface relief
Very high
Principal indices
nω 1.85 · nε 1.87
Michel-Lévy diagramhighlighted lineδ = 0.0200
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]200 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation200 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#99
Cell parameters
a = 5.7241(2) Å · c = 55.539(2) Å
Type-locality form

Aggregates of sub-to-euhedral crystals, up to 100 μm, within fluorite aggregates.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3215.999511.968
37.12%
13AlAluminiumAluminium1626.982431.712
31.30%
50SnTinTin2118.710237.420
17.21%
30ZnZincZinc365.380196.140
14.22%
1HHydrogenHydrogen21.0082.016
0.15%
Total1379.256100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2018-122a
  • Zinconigeriet-6N6S

In other languages

German
IMA 2018-122a · Zinconigerit-6N6S

Classification

Strunz
10th ed.

4.FC.20

  • 4OxidesClass
  • 4.FHydroxides (without V or U)Division
  • 4.FCHydroxides with OH, without H2O; corner-sharing octahedraGroup
  • 4.FC.20Zinconigerite-6N6SSpecies

Group, growth & confusion

In the same group
1 members

Literature, links & citation

Citations
  1. 2002Armbruster, Thomas (2002) Revised nomenclature of högbomite, nigerite, and taaffeite minerals. European Journal of Mineralogy, 14 (2) 389-395 doi:10.1127/0935-1221/2002/0014-0389DOI: 10.1127/0935-1221/2002/0014-0389
  2. 2020Miyawaki, Ritsuro, Hatert, Frédéric, Pasero, Marco, Mills, Stuart J. (2020) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) – Newsletter 56. European Journal of Mineralogy, 32 (4) 443-448 doi:10.5194/ejm-32-443-2020 DOI: 10.5194/ejm-32-443-2020
  3. 2022Rao, Can, Gu, Xiangping, Wang, Rucheng, Xia, Qunke, Dong, Chuanwan, Hatert, Frédéric, Bo, Fabrice Dal, Yu, Xuege, Wang, Wumengyu (2022) Zinconigerite-2N1S ZnSn2Al12O22(OH)2 and zinconigerite-6N6S Zn3Sn2Al16O30(OH)2, two new minerals of the nolanite-spinel polysomatic series from the Xianghualing skarn, Hunan Province, China. American Mineralogist, 107 (10) 1952-1959 doi:10.2138/am-2022-7983DOI: 10.2138/am-2022-7983
