Zirsinalite

Na6CaZrSi6O18
IMA status
  • Approved
IMA symbol
Zsl
Discovered
1973
IMA approved
1973
Also known as
  • IMA1973-025
  • Zirsinaliet
  • Zirsinalit

Where it forms, where it's found

Geological setting

Pegmatitic veinlets cutting alkalic rocks

Type locality
Koashva Open Pit
  1. Koashva Mt
  2. Murmansk Oblast
  3. Russia

67.6167°, 34.0000°

6recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
Colourless · yellowish-grey
Cleavage
None Observed

Fracture 'granular or small conchoidal'

Fracture
Conchoidal
Density
2.88 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.605 – 1.61
Surface relief
Moderate
Principal indices
nω 1.610 · nε 1.605
Michel-Lévy diagramhighlighted lineδ = 0.0050
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]50 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation50 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
R-3m
Cell parameters
a = 10.29(4) Å · c = 13.11(4) Å
Z
3
Morphology

rounded or irregular grains, to 1.5 cm

Type-locality form

Rounded or irregular deposits up to 1 x 1.5 cm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1815.999287.982
39.68%
14SiSiliconSilicon628.085168.510
23.22%
11NaSodiumSodium622.990137.940
19.01%
40ZrZirconiumZirconium191.22491.224
12.57%
20CaCalciumCalcium140.07840.078
5.52%
Total725.734100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • H2O

Synonyms

  • IMA1973-025
  • Zirsinaliet
  • Zirsinalit

In other languages

German
IMA 1973-025 · Zirsinalith
Italian
Zirsinalite

Classification

Strunz
10th ed.

9.CJ.15a

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CJ[Si6O18]12- 6-membered single rings (sechser-Einfachringe), without insular complex anionsGroup
  • 9.CJ.15aZirsinaliteSpecies
Dana
8th ed.

61.01.2a.04

  • 61Cyclosilicates Six-membered RingsClass
  • 61.01Six-Membered Rings with [Si6O18] rings; possible (OH) and Al substitutionType
  • 61.01.2a— unnamed intermediate level —Group
  • 61.01.2a.04ZirsinaliteSpecies
CIM

14.10.32

  • 14Silicates not Containing AluminumClass
  • 14.10Silicates of Zr or HfGroup
  • 14.10.32ZirsinaliteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1974Kapustin, Y.L., Pudovkina, Z.V., Bykova, A.V. (1974) Zirsinalite, a new mineral. Zapiski Vsesoyuznogo Mineralogicheskogo Obshchestva: 103(5): 551-558.
  2. 1975Fleischer, Michael; Chao, G. Y.; Kato, Ikiro (1975) New Mineral Names. American Mineralogist, 60 (5-6). 485-489
  3. 1975Kapustin, Yu.L., Pudovkina, Z.V., Bykova, A.V. (1975) Zirsinalite, a new mineral. International Geology Review, 17 (7) 807-812 doi:10.1080/00206817509471633DOI: 10.1080/00206817509471633
  4. 1980Pudovkina, Z.V., Chernitsova, N.M., Voronkov, A.A., Pyatenko, Y.A. (1980) Crystal structure of zirsinalite Na6Ca{Zr(Si6O18)}. Doklady Akademii Nauk SSSR: 250: 865-867.
  5. 2001(2001) Zirsinalite. Handbook of Mineralogy. Mineralogical Society of America
