Aheylite

Fe2+Al6(PO4)4(OH)8 · 4H2O
IMA status
  • Approved
IMA symbol
Ahe
Discovered
1984
IMA approved
1984
Also known as
  • Aheylitt
  • IMA1984-036

Where it forms, where it's found

Geological setting

A late stage hydrothermal mineral in a base-metal-tin deposit.

Type locality
Huanuni mine
  1. Huanuni
  2. Pantaleón Dalence Province
  3. Oruro
  4. Bolivia

-18.2844°, -66.8331°

7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 5.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Very pale blue · pale green · to blue-green
Streak
greenish white
Tenacity
brittle
Cleavage
Perfect

(001), also (010) good

Fracture
Hackly
Density
3.22 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
1.63
Surface relief
Moderate
Principal indices
nβ 1.63
Pleochroism
Non-pleochroic
Dispersion
r > v
UV response
Non-fluorescent
Notes

Mean RI 1.63. Individual indices could not be determined due to small grain size.

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 7.885 Å · b = 10.199 Å · c = 7.672 Å
Cell angles
α = 110.84 ° · β = 115.12 ° · γ = 67.51 °
Ratio a:b:c
1 : 1.293 : 0.973
Z
1
Morphology

Dense clusters of crystals ideally displaying typical turquoise group morphology: short prismatic with large (001), (010), {1-10}, and {-1-11}.

Type-locality form

Isolated and aggregate clumps of hemispherical or spherical, radiating to interlocked masses of crystals that average 3 µm in maximum dimension.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2815.999447.972
55.60%
13AlAluminiumAluminium626.982161.892
20.09%
15PPhosphorusPhosphorus430.974123.896
15.38%
26FeIronIron155.84555.845
6.93%
1HHydrogenHydrogen161.00816.128
2.00%
Total805.733100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Aheylitt
  • IMA1984-036

In other languages

French
aheylite
German
Aheylit · IMA 1984-036
Spanish
Aheylita
Italian
aheylite
Japanese
アヘイル石
Chinese
阿铁绿松石
Arabic
أهيليت

Classification

Strunz
10th ed.

8.DD.15

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DDWith only medium-sized cations, (OH, etc.):RO4= 2:1Group
  • 8.DD.15AheyliteSpecies
Dana
8th ed.

42.09.03.05

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.09(AB)7(XO4)4Zq·xH2OType
  • 42.09.03Turquoise GroupGroup
  • 42.09.03.05AheyliteSpecies
CIM

19.6.11

  • 19PhosphatesClass
  • 19.6Phosphates of ZnGroup
  • 19.6.11AheyliteSpecies

Group, growth & confusion

In the same group
4 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1998Foord, Eugene E., Taggart, Joseph E. (1998) A reexamination of the turquoise group: the mineral aheylite, planerite (redefined), turquoise and coeruleolactite. Mineralogical Magazine, 62 (1) 93-111 doi:10.1180/002646198547495 DOI: 10.1180/002646198547495
  2. 2005(2005) Aheylite. Handbook of Mineralogy. Mineralogical Society of America
