Airdite

Sr(V4+O)2(PO4)2 · 4H2O
IMA status
  • Approved
IMA symbol
Air
IMA approved
2020
Also known as
  • Airdiet
  • Airditt
  • IMA2020-046

Where it forms, where it's found

Geological setting

crystallized from low-temperature hydrothermal solutions in small cavities in quartz veins.

Type locality
Spring Creek Mine
  1. Wilmington
  2. District Council of Mount Remarkable
  3. South Australia
  4. Australia

-32.7311°, 138.1269°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
pale green
Tenacity
brittle
Cleavage
Perfect

(001)

Density
3.116 g/cm³

Optical

Optical type
Biaxial (-)
Refractive index
1.69 – 1.696
Surface relief
High
Principal indices
nα 1.690 · nβ 1.696 · nγ 1.696
Michel-Lévy diagramhighlighted lineδ = 0.0060
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]60 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation60 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
Cc
Cell parameters
a = 9.006(2) Å · b = 8.991(2) Å · c = 12.796(3) Å
Cell angles
β = 100.25(3) °
Ratio a:b:c
1 : 0.998 : 1.421
Z
4
Type-locality form

thin platy crystals up to 80 μm in length and crystal clusters up to 0.5 mm across

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
46.33%
23VVanadiumVanadium250.942101.884
21.07%
38SrStrontiumStrontium187.62087.620
18.12%
15PPhosphorusPhosphorus230.97461.948
12.81%
1HHydrogenHydrogen81.0088.064
1.67%
Total483.502100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Airdiet
  • Airditt
  • IMA2020-046

In other languages

German
Airdit · IMA 2020-046

Classification

Strunz
10th ed.

8.CJ

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CJWith only large cationsGroup
  • 8.CJAirditeSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 2020Miyawaki, Ritsuro, Hatert, Frédéric, Pasero, Marco, Mills, Stuart J. (2020) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) – Newsletter 57. European Journal of Mineralogy, 32 (5) 495-499 doi:10.5194/ejm-32-495-2020 DOI: 10.5194/ejm-32-495-2020
  2. 2022(2022) Airdite. Handbook of Mineralogy. Mineralogical Society of America
  3. 2025Elliott, Peter; Kampf, Anthony R. (2025) Airdite, Sr(V4+O)2(PO4)2·4H2O, a New Mineral from the Spring Creek Copper Mine, South Australia, Australia. The Canadian Journal of Mineralogy and Petrology, 63 (2). 191-192 doi:10.3749/2400022DOI: 10.3749/2400022
