Bariosincosite

Ba(VO)2(PO4)2 · 4H2O
IMA status
  • Approved
IMA symbol
Bscs
Also known as
  • Bariosincosiet
  • IMA1998-047

Where it forms, where it's found

Geological setting

Of low-temperature late-stage hydrothermal or supergene origin in a small vein.

Type locality
Spring Creek Mine
  1. Wilmington
  2. District Council of Mount Remarkable
  3. South Australia
  4. Australia

-32.7311°, 138.1269°

3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
Pale green with a slight bluish tinge.
Streak
Very pale green
Cleavage
Distinct/Good

Distinct on (001).

Fracture
Splintery
Density
3.40 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.715 – 1.721
Surface relief
High
Principal indices
nω 1.721 · nε 1.715
Pleochroism
Weak

E = colorless, O = pale green.

Michel-Lévy diagramhighlighted lineδ = 0.0060
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]60 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation60 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Cell parameters
a = 9.031(6) Å · c = 12.755(8) Å
Z
4
Morphology

Pseudotetragonal, subparallel plates, often arranged in rosettes.

Type-locality form

irregular clusters of divergent crystals to 250 μm

Comment

Point Group: 4/m or 4/m 2/m 2/m. ; Space Group: P4/n or P4/nmm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
42.01%
56BaBariumBarium1137.327137.327
25.75%
23VVanadiumVanadium250.942101.884
19.11%
15PPhosphorusPhosphorus230.97461.948
11.62%
1HHydrogenHydrogen81.0088.064
1.51%
Total533.209100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Bariosincosiet
  • IMA1998-047

In other languages

German
Bariosincosit · IMA 1998-047
Spanish
bariosincosita
Italian
Bariosincosite

Classification

Strunz
10th ed.

8.CJ.65

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CJWith only large cationsGroup
  • 8.CJ.65BariosincositeSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 1999Pring, A., Kolitsch, U., Birch, W. D., Beyer, B. D., Elliott, P., Ayyappan, P., Ramanan, A. (1999) Bariosincosite, a new hydrated barium vanadium phosphate, from the Spring Creek Mine, South Australia. Mineralogical Magazine, 63 (5) 735-741 doi:10.1180/minmag.1999.063.5.10 DOI: 10.1180/minmag.1999.063.5.10
  2. 2021(2021) Bariosincosite. Handbook of Mineralogy. Mineralogical Society of America
