Sincosite

Ca(VO)2(PO4)2 · 4H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Scs
Discovered
1922
Also known as
  • Sincosiet

Where it forms, where it's found

Geological setting

Veinlets in Cretaceous black carbonaceous shale

Type locality
Sincos
  1. Sincos district
  2. Jauja province
  3. Junín
  4. Peru

-11.9167°, -75.3333°

13recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789101 – 2/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Grass-green · yellow- to olive-green · brownish green · blue-green · light green · olive-green · brownish green · yellowish green · bluish green in transmitted light.

Typically zoned parallel to {001}.

Streak
Green
Tenacity
brittle
Cleavage
Perfect

On (001) perfect, on (110) good, on (010) poor.

Density
2.84 g/cm³

Optical

Optical type
Uniaxial (-) · 2V measured = 10 – 83°
Refractive index
1.655 – 1.694
Surface relief
High
Principal indices
nα 1.67 – 1.675 · nβ 1.69 · nγ 1.693 – 1.694 · nω 1.68 · nε 1.655
Pleochroism
Visible

E = X = Nearly colourless to pale yellow O = Z = Grey-green

Notes

Partially biaxial (-) if dehydrated.

Michel-Lévy diagramhighlighted lineδ = 0.0210
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]210 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation210 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
#194
Cell parameters
a = 8.895 Å · c = 12.727 Å
Z
4
Morphology

Crystals thin tabular, square to rectangular, with (001), (010), and (110); striated on (001) parallel [100] and [110]; may be composite with many superposed plates in nearly parallel position. Forms rosettes, crudely radial and in scaly aggregates; botryoidal to nodular massive.

Twinning

On (110), rare.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
51.38%
23VVanadiumVanadium250.942101.884
23.37%
15PPhosphorusPhosphorus230.97461.948
14.21%
20CaCalciumCalcium140.07840.078
9.19%
1HHydrogenHydrogen81.0088.064
1.85%
Total435.960100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Sincosiet

In other languages

French
sincosite
German
Sincosit
Spanish
Sincosita
Italian
sincosite

Classification

Strunz
10th ed.

8.CJ.65

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CJWith only large cationsGroup
  • 8.CJ.65SincositeSpecies
Dana
8th ed.

42.11.19.01

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.11(AB)3(XO4)2Zq·xH2OType
  • 42.11.19Sincosite GroupGroup
  • 42.11.19.01SincositeSpecies
CIM

19.10.10

  • 19PhosphatesClass
  • 19.10Phosphates of Pb, Th, V and BiGroup
  • 19.10.10SincositeSpecies

Group, growth & confusion

In the same group
3 members
Often grow together
2 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1922Wherry, E.T. (1922) New minerals: new species. American Mineralogist: 7: 162-164.
  2. 1922Schaller, W.T. (1922) Sincosite, a new mineral. Journal of the Washington Academy of Sciences, 12. p.195.
  3. 1924Schaller, W.T. (1924) The occurrence and properties of sincosite, a new vanadium mineral from Sincos, Peru. American Journal of Science: 8: 462-480.
  4. 1925Foshag, W.F. (1925) New mineral names. American Mineralogist: 10: 131-135.
  5. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
