Alicewilsonite-(YLa)

Na2Sr2YLa(CO3)6 · 3H2O
IMA status
  • Approved
IMA symbol
Aws-YLa
Also known as
  • Alicewilsoniet-(YLa)
  • Alicewilsonitt-(YLa)
  • IMA2021-047

Where it forms, where it's found

Geological setting

dolomites, sandstones, and shales of the Torrensian Burra Group were disrupted by several dolerite bodies and were brecciated forming the “Paratoo Diapir”. At its surface, the bulk of the copper mineralisation occurs in the quartz–magnetite veins, and as impregnations and fissure fillings of secondary copper minerals in sedimentary rocks. The secondary Cu-REE mineralisation, including alicewilsonite-(YLa), associated with the intensely weathered base metal and magnetite ores, occurs as thin coatings along bedding joints and fractures and is most abundant near the surface (< 3 m)

Type locality
Paratoo copper Mine
  1. Paratoo
  2. District Council of Peterborough
  3. South Australia
  4. Australia

-32.6795°, 139.3304°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
pale pink to colourless
Streak
white
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
3.37 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 60° · 2V calc = 63°
Refractive index
1.556 – 1.592
Surface relief
Moderate
Principal indices
nα 1.556 · nβ 1.582 · nγ 1.592
Pleochroism
Non-pleochroic
UV response
non-fluorescent under ultraviolet light
Michel-Lévy diagramhighlighted lineδ = 0.0360
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]360 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation360 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#1
Cell parameters
a = 8.9793(3) Å · b = 8.9734(2) Å · c = 6.7404(2) Å
Cell angles
α = 102.829(2) ° · β = 116.382(3) ° · γ = 60.109(3) °
Ratio a:b:c
1 : 0.999 : 0.751
Z
1
Type-locality form

pseudohexagonal tabular crystals up to 150 µm in size

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2115.999335.979
38.93%
38SrStrontiumStrontium287.620175.240
20.30%
57LaLanthanumLanthanum1138.905138.905
16.09%
39YYttriumYttrium188.90688.906
10.30%
6CCarbonCarbon612.01172.066
8.35%
11NaSodiumSodium222.99045.980
5.33%
1HHydrogenHydrogen61.0086.048
0.70%
Total863.124100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Alicewilsoniet-(YLa)
  • Alicewilsonitt-(YLa)
  • IMA2021-047

In other languages

German
Alicewilsonit-(YLa) · IMA 2021-047

Classification

Strunz
10th ed.

5.CC.05

  • 5CarbonatesClass
  • 5.CCarbonates without additional anions, with H2ODivision
  • 5.CCWith rare earth elements (REE)Group
  • 5.CC.05Alicewilsonite-(YLa)Species

Group, growth & confusion

Literature, links & citation

Citations
  1. 2021Miyawaki, Ritsuro, Hatert, Frédéric, Pasero, Marco, Mills, Stuart J. (2021) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) CNMNC Newsletter No 63. Mineralogical Magazine, 85 (6) 910-915 doi:10.1180/mgm.2021.74 DOI: 10.1180/mgm.2021.74
  2. 2022(2022) Alicewilsonite-(YLa). Handbook of Mineralogy. Mineralogical Society of America
  3. 2024Lykova, Inna; Rowe, Ralph; Poirier, Glenn; Friis, Henrik; Helwig, Kate (2024) Mckelveyite group minerals – Part 4: Alicewilsonite-(YLa), Na2Sr2YLa(CO3)6  ⋅  3H2O, a new lanthanum-dominant species from the Paratoo mine, Australia. European Journal of Mineralogy, 36 (2). 301-310 doi:10.5194/ejm-36-301-2024DOI: 10.5194/ejm-36-301-2024
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Alicewilsonite-(YLa) — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/alicewilsonite-yla-55597},
  note      = {Accessed 2026-05-11}
}
