Donnayite-(Y)

NaSr3CaY(CO3)6 · 3H2O
IMA status
  • Approved
IMA symbol
Dna-Y
Discovered
1973
Also known as
  • Donnayiet-(Y)
  • IMA1978-007

Where it forms, where it's found

Geological setting

Pegmatite dykes, miarolitic cavities and interstices in nepheline syenite.

Type locality
Poudrette quarry (De-Mix quarry
  1. Demix quarry
  2. Uni-Mix quarry
  3. Carrière Mont Saint-Hilaire
  4. MSH)
  5. Mont Saint-Hilaire
  6. La Vallée-du-Richelieu RCM
  7. Montérégie
  8. Québec
  9. Canada

45.5628°, -73.1417°

11recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
pale yellow to yellow · colorless · white · grey · brown to reddish brown
Streak
White
Cleavage
Imperfect/Fair

Basal cleavage indistinct to fair

Density
3.30 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 20° · 2V calc = 26 – 28°
Refractive index
1.551 – 1.652
Surface relief
Moderate
Principal indices
nα 1.551 – 1.561 · nβ 1.646 · nγ 1.652
Dispersion
r > v strong
Michel-Lévy diagramhighlighted lineδ = 0.0960
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]960 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation960 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#1
Cell parameters
a = 9.000 Å · b = 8.999 Å · c = 6.793 Å
Cell angles
α = 102.77 ° · β = 116.28 ° · γ = 59.99 °
Ratio a:b:c
1 : 1.000 : 0.755
Z
1
Type-locality form

Platy, tabular, columnar, saucer-shaped, barrel-shaped to irregularly granular. Crystals to 2 mm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2115.999335.979
40.53%
38SrStrontiumStrontium387.620262.860
31.71%
39YYttriumYttrium188.90688.906
10.73%
6CCarbonCarbon612.01172.066
8.69%
20CaCalciumCalcium140.07840.078
4.84%
11NaSodiumSodium122.99022.990
2.77%
1HHydrogenHydrogen61.0086.048
0.73%
Total828.927100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Donnayiet-(Y)
  • IMA1978-007

In other languages

German
Donnayit-(Y) · IMA 1978-007
Italian
Donnayite- · Donnayite-(Y)
Chinese
碳钇锶石

Classification

Strunz
10th ed.

5.CC.05

  • 5CarbonatesClass
  • 5.CCarbonates without additional anions, with H2ODivision
  • 5.CCWith rare earth elements (REE)Group
  • 5.CC.05Donnayite-(Y)Species
Dana
8th ed.

15.03.04.01

  • 15Hydrated Normal CarbonatesClass
  • 15.03AmBn(XO3)p·xH2O, with (m+n):p = 1:1Type
  • 15.03.04Mckelveyite GroupGroup
  • 15.03.04.01Donnayite-(Y)Species
CIM

11.8.16

  • 11CarbonatesClass
  • 11.8Carbonates of the rare earthsGroup
  • 11.8.16Donnayite-(Y)Species

Group, growth & confusion

Literature, links & citation

Citations
  1. 1978Chao, George Y., Mainwaring, P. R., Baker, J. (1978) Donnayite, NaCaSr3Y(CO3)6·3H2O, a new mineral from Mont St-Hilaire, Québec. The Canadian Mineralogist, 16 (3) 335-340
  2. 1984Trinh, T.L.T., Pobedimskaya, E.A., Nadezhina, T.N., and Khomyakov, A.P. (1984) The crystal structures of alkaline carbonates; barentsite, bonshtedtite and donnayite. Acta Crystallographica, A40 (Supplement), C257 (abstract).
  3. 1987Nickel, Ernest H., Mandarino, Joseph A. (1987) Procedures involving the IMA Commission on New Minerals and Mineral Names and guidelines on mineral nomenclature. American Mineralogist, 72 (9-10) 1031-1042
  4. 2005(2005) Donnayite-(Y). Handbook of Mineralogy. Mineralogical Society of America
  5. 2023Lykova, Inna; Rowe, Ralph; Poirier, Glenn; Giester, Gerald; Ojaste, Kelsie; Friis, Henrik (2023) Mckelveyite group minerals – Part 1: Nomenclature and new data on donnayite-(Y). European Journal of Mineralogy, 35 (1). 133-142 doi:10.5194/ejm-35-133-2023 DOI: 10.5194/ejm-35-133-2023
