Allanite-(La)

CaLa(Al2Fe2+)[Si2O7][SiO4]O(OH)
IMA status
  • Approved
IMA symbol
Aln-La
IMA approved
2003
Also known as
  • Allaniet-(La)
  • Allanitt-(La)
  • IMA2003-065

Where it forms, where it's found

Geological setting

baryte veins cutting a dolomitic metamorphosed limestone

Type locality
Buca della Vena Mine
  1. Pontestazzemese
  2. Stazzema
  3. Lucca Province
  4. Tuscany
  5. Italy

43.9986°, 10.2944°

23recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Black · with brownish reflections
Streak
Brown
Tenacity
brittle
Cleavage
Imperfect/Fair

along (001)

Fracture
Conchoidal
Density
3.93 g/cm³

Optical

Optical type
Biaxial (-) · 2V calc = 90°
Refractive index
1.755 – 1.765
Surface relief
High
Principal indices
nα 1.755 · nβ 1.76 · nγ 1.765
Pleochroism
Strong

greenish to greenish brown

Dispersion
very high
UV response
None
Michel-Lévy diagramhighlighted lineδ = 0.0100
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]100 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation100 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#15
Cell parameters
a = 8.914 Å · b = 5.726 Å · c = 10.132 Å
Cell angles
β = 114.87 °
Ratio a:b:c
1 : 0.642 : 1.137
Unit cell volume
469.1 ų
Z
2
Morphology

prismatic crystals, elongated along [010] observed forms: (001), (100), (101), (101), (210) and (011)

Type-locality form

prismatic crystals up to 2–3 mm in length

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1315.999207.987
35.73%
57LaLanthanumLanthanum1138.905138.905
23.87%
14SiSiliconSilicon328.08584.255
14.48%
26FeIronIron155.84555.845
9.59%
13AlAluminiumAluminium226.98253.964
9.27%
20CaCalciumCalcium140.07840.078
6.89%
1HHydrogenHydrogen11.0081.008
0.17%
Total582.042100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Allaniet-(La)
  • Allanitt-(La)
  • IMA2003-065

In other languages

German
Allanit-(La) · IMA 2003-065
Italian
Allanite- · allanite-(La)

Classification

Strunz
10th ed.

9.BG.05b

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BGSorosilicates with mixed SiO4 and Si2O7 groups; cations in octahedral [6] and greater coordinationGroup
  • 9.BG.05bAllanite-(La)Species
Dana
8th ed.

58.02.1a.02

  • 58Sorosilicates Insular, Mixed, Single, and Larger Tetrahedral GroupsClass
  • 58.02Insular, Mixed, Single, and Larger Tetrahedral Groups with cations in [6] and higher coordination; single and double groups (n = 1, 2)Type
  • 58.02.1a— unnamed intermediate level —Group
  • 58.02.1a.02Allanite-(La)Species

Group, growth & confusion

Literature, links & citation

Citations
  1. 1940Marble, John Putnam (1940) Allanite from Barringer Hill, Llano County, Texas. American Mineralogist, 25 (3) 168-173
  2. 1951Hutton, C. Osborne (1951) Allanite from Yosemite National Park, Tuolumne, Co., California. American Mineralogist, 36 (3-4) 233-248
  3. 1951Hutton, C. O. (1951) Allanite from Wilmot Pass, Fiordland, New Zealand. American Journal of Science, 249 (3) 208-214 doi:10.2475/ajs.249.3.208DOI: 10.2475/ajs.249.3.208
  4. 1957Hasegawa, S. (1957) Chemical studies of allanites and their associated minerals from the pegmatites in the northern part of the Abukuma massif. Science Reports, Tohoku University, Series 3, Mineralogy, Petrology, and Economic Geology: 5: 345-371.
  5. 1958Hasegawa, S. (1958) Chemical studies of allanites from the new localities in Fukushima and Kagawa prefectures. Science Reports, Tohoku University, Ser. 3, Mineralogy, Petrology, and Economic Geology, 6, 39-56.
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Allanite-(La) — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/allanite-la-126},
  note      = {Accessed 2026-05-11}
}
