Allanite-(Ce)

CaCe(Al2Fe2+)[Si2O7][SiO4]O(OH)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Aln-Ce
Also known as
  • Allaniet-(Ce)
  • Allanitt-(Ce)
  • Cerepidote
  • +2 more

Where it forms, where it's found

Geological setting

A common accessory mineral in many igneous rocks, particularly those that are felsic, and metamorphosed igneous rocks. Also in pegmatites, skarns, and tactites. Not common in volcanic rocks. A detrital mineral.

Type locality
Qáqarssuatsiaq
  1. Aluk Island
  2. Kujalleq
  3. Greenland

60.1619°, -43.0331°

751recorded occurrences
Source · OpenStreetMap

Varieties

Physical

Hardness
123456789105.5 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Sub-metallic · pitchy · resinous
Transparency
Translucent · Opaque
Colour
Brown to black

brown or green in thin section

Streak
Brown, greyish
Tenacity
brittle
Cleavage
Imperfect/Fair

Imperfect on (001) ; poor on (100) and (110)

Fracture
Irregular/Uneven · Conchoidal
Density
3.5 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 40 – 80° · 2V calc = 50 – 56°
Refractive index
1.715 – 1.822
Surface relief
High
Principal indices
nα 1.715 – 1.791 · nβ 1.718 – 1.815 · nγ 1.733 – 1.822
Pleochroism
Visible

X = pale olive-green, reddish brown; Y = dark brown, brownish yellow; Z = dark reddish brown, greenish brown.

Dispersion
distinct to strong
Notes

Metamict allanites are isotropic with N as low as 1.61.

Michel-Lévy diagramhighlighted lineδ = 0.0245
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]245 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation245 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#15
Cell parameters
a = 8.927 Å · b = 5.761 Å · c = 10.15 Å
Cell angles
β = 114.77 °
Ratio a:b:c
1 : 0.645 : 1.137
Z
2
Morphology

Crystals tabular parallel to (100), or prismatic to acicular parallel to [010] , to 90 cm; granular, massive.

Twinning

Polysynthetic, common on (100) .

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1315.999207.987
35.66%
58CeCeriumCerium1140.116140.116
24.02%
14SiSiliconSilicon328.08584.255
14.45%
26FeIronIron155.84555.845
9.58%
13AlAluminiumAluminium226.98253.964
9.25%
20CaCalciumCalcium140.07840.078
6.87%
1HHydrogenHydrogen11.0081.008
0.17%
Total583.253100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Allaniet-(Ce)
  • Allanitt-(Ce)
  • Cerepidote
  • Cerorthit
  • Cerorthite

In other languages

German
Allanit-(Ce)
Spanish
Allanita · Allanita-
Italian
Allanite- · allanite-(Ce)
Chinese
铈褐帘石

Classification

Strunz
10th ed.

9.BG.05b

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BGSorosilicates with mixed SiO4 and Si2O7 groups; cations in octahedral [6] and greater coordinationGroup
  • 9.BG.05bAllanite-(Ce)Species
Dana
8th ed.

58.02.1a.01

  • 58Sorosilicates Insular, Mixed, Single, and Larger Tetrahedral GroupsClass
  • 58.02Insular, Mixed, Single, and Larger Tetrahedral Groups with cations in [6] and higher coordination; single and double groups (n = 1, 2)Type
  • 58.02.1a— unnamed intermediate level —Group
  • 58.02.1a.01Allanite-(Ce)Species
CIM

16.13.5

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.13Aluminosilicates of the rare earthsGroup
  • 16.13.5Allanite-(Ce)Species

Group, growth & confusion

Often grow together
4 minerals

Literature, links & citation

Citations
  1. 1810Thomson, T. (1810) Experiments on allanite, a new mineral from Greenland. Transactions of the Royal Society of Edinburgh: 8: 371-386.
  2. 1940Marble, John Putnam (1940) Allanite from Barringer Hill, Llano County, Texas. American Mineralogist, 25 (3) 168-173
  3. 1951Hutton, C. Osborne (1951) Allanite from Yosemite National Park, Tuolumne, Co., California. American Mineralogist, 36 (3-4) 233-248
  4. 1951Hutton, C. O. (1951) Allanite from Wilmot Pass, Fiordland, New Zealand. American Journal of Science, 249 (3) 208-214 doi:10.2475/ajs.249.3.208DOI: 10.2475/ajs.249.3.208
  5. 1957Hasegawa, S. (1957) Chemical studies of allanites and their associated minerals from the pegmatites in the northern part of the Abukuma massif. Science Reports, Tohoku University, Series 3, Mineralogy, Petrology, and Economic Geology: 5: 345-371.
