Bergslagite

CaBe(AsO4)(OH)
IMA status
  • Approved
IMA symbol
Bgl
Discovered
1975
IMA approved
1983
Also known as
  • Bergslagiet
  • IMA1983-021

Where it forms, where it's found

Type locality
Långban Mine
  1. Långban Ore District
  2. Filipstad
  3. Värmland County
  4. Sweden

59.8554°, 14.2648°

7recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Translucent
Colour
Colourless · white · grey · dark grey-brown · brownish black · green · pink
Fracture
Irregular/Uneven
Density
3.4 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 70° · 2V calc = 74 – 78°
Refractive index
1.659 – 1.694
Surface relief
High
Principal indices
nα 1.659 – 1.66 · nβ 1.678 – 1.681 · nγ 1.69 – 1.694
Dispersion
r >> v
UV response
SW-UV: pale shades of yellowish brown, greenish or bluish
Michel-Lévy diagramhighlighted lineδ = 0.0325
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]325 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation325 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#14
Cell parameters
a = 4.88 Å · b = 7.8 Å · c = 10.12 Å
Cell angles
β = 90.16 °
Ratio a:b:c
1 : 1.598 : 2.074
Z
4
Morphology

elongated flattened crystals to 1 cm; crusts

Type-locality form

As thin veinlets in hematite ore

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen515.99979.995
39.02%
33AsArsenicArsenic174.92274.922
36.54%
20CaCalciumCalcium140.07840.078
19.55%
4BeBerylliumBeryllium19.0129.012
4.40%
1HHydrogenHydrogen11.0081.008
0.49%
Total205.015100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Si

Synonyms

  • Bergslagiet
  • IMA1983-021

In other languages

German
Bergslagit · IMA 1983-021
Italian
Bergslagite

Classification

Strunz
10th ed.

8.BA.10

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BAWith small and medium-sized cationsGroup
  • 8.BA.10BergslagiteSpecies
Dana
8th ed.

41.05.04.04

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.05(AB)2(XO4)ZqType
  • 41.05.04Herderite GroupGroup
  • 41.05.04.04BergslagiteSpecies
CIM

20.2.16

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.2Arsenates of Be, Mg, Ca or BaGroup
  • 20.2.16BergslagiteSpecies

Group, growth & confusion

In the same group
2 members
Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1984Hansen, Staffan, Fälth, Lars, Johnsen, Ole (1984) Bergslagite, a mineral with tetrahedral berylloarsenate sheet anions. Zeitschrift für Kristallographie - Crystalline Materials, 166 (14). 73-80 doi:10.1524/zkri.1984.166.14.73 DOI: 10.1524/zkri.1984.166.14.73
  2. 1984Hansen, S., Fälth, L., Petersen, O. V., Johnson, O. (1984) Bergslagite, a new mineral species from Långban, Sweden. Neues Jahrbuch für Mineralogie - Monatshefte, 1984. 257-262
  3. 1985Dunn, Pete J., Gobel, Volker, Grice, Joel D., Puziewicz, Jacek, Shigley, James E., Vanko, David A., Zilczer, Janet (1985) New mineral names. American Mineralogist, 70 (3-4) 436-441
  4. 1989Jambor, John L., Vanko, David A. (1989) New mineral names. American Mineralogist, 74 (7-8) 946-951
  5. 1996Kolitsch, Uwe (1996) Bergslagit aus dem Rhyolith-Steinbruch bei Sailauf im Spessart [Bergslagite from the rhyolite quarry near Sailauf in the Spessart region]. Mineralien-Welt, 7 (5). 45-46
