Bertossaite

Li2CaAl4(PO4)4(OH)4
IMA status
  • Approved
IMA symbol
Bts
Discovered
1965
IMA approved
1965
Also known as
  • Bertossaiet
  • IMA1965-038

Where it forms, where it's found

Geological setting

A lithium pegmatite

Type locality
Buranga pegmatite
  1. Muhororo
  2. Ngororero District
  3. Western Province
  4. Rwanda

-1.9214°, 29.6542°

8recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Translucent
Colour
Pale pink
Cleavage
Distinct/Good

(100)

Fracture
Irregular/Uneven · Sub-Conchoidal
Density
3.10 g/cm³

Optical

Optical type
Biaxial (-) · 2V calc = 53°
Refractive index
1.624 – 1.642
Surface relief
Moderate
Principal indices
nα 1.624 · nβ 1.636 · nγ 1.642
Dispersion
weak
Extinction
Parallel. X = a; Y = c; Z = b.
UV response
None
Notes

2Vmeas: moderately large.

Michel-Lévy diagramhighlighted lineδ = 0.0180
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]180 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation180 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 11.476(1) Å · b = 15.744(2) Å · c = 7.228(1) Å
Ratio a:b:c
1 : 1.372 : 0.630
Z
4
Morphology

Massive

Comment

Space Group: Imcb. Cell parameters from Hatert et al. (2011).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2015.999319.980
52.47%
15PPhosphorusPhosphorus430.974123.896
20.32%
13AlAluminiumAluminium426.982107.928
17.70%
20CaCalciumCalcium140.07840.078
6.57%
3LiLithiumLithium26.94013.880
2.28%
1HHydrogenHydrogen41.0084.032
0.66%
Total609.794100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Mn

Synonyms

  • Bertossaiet
  • IMA1965-038

In other languages

French
Bertossaïte
German
Bertossait · IMA 1965-038
Italian
Bertossaite
Chinese
磷铝钙锂石

Classification

Strunz
10th ed.

8.BH.25

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BHWith medium-sized and large cations, (OH,etc.):RO4 = 1:1Group
  • 8.BH.25BertossaiteSpecies
Dana
8th ed.

41.07.01.02

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.07(AB)7(XO4)4ZqType
  • 41.07.01Palermoite GroupGroup
  • 41.07.01.02BertossaiteSpecies
CIM

19.8.5

  • 19PhosphatesClass
  • 19.8Phosphates of Al and other metalsGroup
  • 19.8.5BertossaiteSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 1965von Knorring, O. (1965) Notes on some pegmatite minerals from Rwanda. Bulletin du Service Géologique de Rwanda: 2: 11-14.
  2. 1966Von Knorring, O. and Mrose, M.E. (1966) Bertossaite (Li,Na)2(Ca,Fe,Mn)Al4 (PO4)(OH,F)4, a new mineral from Rwanda (Africa). (Abstr.) The Canadian Mineralogist: 8: 668. https://rruff.info/uploads/CM8_668.pdf
  3. 1967Fleischer, M. (1967) New Mineral Names. American Mineralogist, 52 (9-10) 1579-1589
  4. 1972Povarennykh, A.S. (1972) Crystal Chemical Classification of Minerals (Plenum, New York, London), 2: 545p. (as Ca-palermoite).
  5. 1998Daltry, V.D.C., von Knorring, O. (1998) Type-mineralogy of Rwanda with particular reference to the Buranga pegmatite. Geologica Belgica: 1: 9-15. https://popups.uliege.be/1374-8505/index.php?id=1593
