Natropalermoite

Na2SrAl4(PO4)4(OH)4
IMA status
  • Approved
IMA symbol
Npl
IMA approved
2013
Also known as
  • IMA2013-118
  • Natropalermoiet

Where it forms, where it's found

Geological setting

Complex, phosphate-bearing pegmatite.

Type locality
Palermo No. 1 Mine
  1. Groton
  2. Grafton County
  3. New Hampshire
  4. USA

43.7513°, -71.8896°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless
Streak
White
Tenacity
brittle
Cleavage
Perfect

on (001); also fair on (100)

Fracture
Sub-Conchoidal · Fibrous
Density
3.502 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 43° · 2V calc = 38°
Refractive index
1.624 – 1.643
Surface relief
Moderate
Principal indices
nα 1.624 · nβ 1.641 · nγ 1.643
Dispersion
Medium to weak, v > r.
Michel-Lévy diagramhighlighted lineδ = 0.0190
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]190 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation190 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 11.4849(6) Å · b = 16.2490(7) Å · c = 7.2927(4) Å
Ratio a:b:c
1 : 1.415 : 0.635
Unit cell volume
1360.95 ų
Z
4
Morphology

Prismatic crystals with striations parallel to the direction of elongation up to 200 x 50 x 45 μm in size

Parting
Not observed
Type-locality form

Prismatic crystals, up to 200 x 50 x 45 μm, striated parallel to the direction of elongation (i.e., the a axis) .

Comment

Imcb

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2015.999319.980
46.41%
15PPhosphorusPhosphorus430.974123.896
17.97%
13AlAluminiumAluminium426.982107.928
15.65%
38SrStrontiumStrontium187.62087.620
12.71%
11NaSodiumSodium222.99045.980
6.67%
1HHydrogenHydrogen41.0084.032
0.59%
Total689.436100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2013-118
  • Natropalermoiet

In other languages

German
IMA 2013-118 · Natropalermoit
Italian
natropalermoite

Classification

Strunz
10th ed.

8.BH.25

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BHWith medium-sized and large cations, (OH,etc.):RO4 = 1:1Group
  • 8.BH.25NatropalermoiteSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 2014Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2014) New minerals and nomenclature modifications approved in 2014, CNMNC Newsletter No 19. Mineralogical Magazine, 78 (1) 165-170 doi:10.1180/minmag.2014.078.1.12DOI: 10.1180/minmag.2014.078.1.12
  2. 2017(2017) Natropalermoite. Handbook of Mineralogy. Mineralogical Society of America
  3. 2017Schumer, Benjamin N., Yang, Hexiong, Downs, Robert T. (2017) Natropalermoite, Na2SrAl4(PO4)4(OH)4, a new mineral isostructural with palermoite, from the Palermo No. 1 mine, Groton, New Hampshire, USA. Mineralogical Magazine, 81 (4) 833-840 doi:10.1180/minmag.2016.080.133DOI: 10.1180/minmag.2016.080.133
