Palermoite

Li2SrAl4(PO4)4(OH)4
IMA status
  • Approved
  • Grandfathered
IMA symbol
Ple
Discovered
1952
Also known as
  • Palermoiet

Where it forms, where it's found

Geological setting

granite pegmatite

Type locality
Palermo No. 1 Mine
  1. Groton
  2. Grafton County
  3. New Hampshire
  4. USA

43.7513°, -71.8896°

6recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
Colorless · white · pale pink
Streak
White
Tenacity
brittle
Cleavage
Perfect

(001), perfect; on (100), fair

Fracture
Sub-Conchoidal · Fibrous
Density
3.22 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 20° · 2V calc = 38°
Refractive index
1.627 – 1.644
Surface relief
Moderate
Principal indices
nα 1.627 · nβ 1.642 · nγ 1.644
Dispersion
r > v or r < v
Michel-Lévy diagramhighlighted lineδ = 0.0170
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]170 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation170 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 11.556(5) Å · b = 15.847(7) Å · c = 7.315(4) Å
Ratio a:b:c
1 : 1.371 : 0.633
Z
4
Comment

Space Group: Imcb

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2015.999319.980
48.68%
15PPhosphorusPhosphorus430.974123.896
18.85%
13AlAluminiumAluminium426.982107.928
16.42%
38SrStrontiumStrontium187.62087.620
13.33%
3LiLithiumLithium26.94013.880
2.11%
1HHydrogenHydrogen41.0084.032
0.61%
Total657.336100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Palermoiet

In other languages

French
Palermoite
German
Palermoit
Italian
Palermoite

Classification

Strunz
10th ed.

8.BH.25

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BHWith medium-sized and large cations, (OH,etc.):RO4 = 1:1Group
  • 8.BH.25PalermoiteSpecies
Dana
8th ed.

41.07.01.01

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.07(AB)7(XO4)4ZqType
  • 41.07.01Palermoite GroupGroup
  • 41.07.01.01PalermoiteSpecies
CIM

19.5.5

  • 19PhosphatesClass
  • 19.5Phosphates of Sr and BaGroup
  • 19.5.5PalermoiteSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 1953Mrose, Mary E. (1953) Palermoite and goyazite, two strontium minerals from the Palermo Mine, North Groton, New Hampshire. American Mineralogist, 38 (3-4) 354
  2. 1965Frondel, Clifford, Ito, Jun (1965) Composition of palermoite. American Mineralogist, 50 (5-6) 777-779
  3. 1975Moore, Paul B., Araki, Takaharu (1975) Palermoite, SrLi2[Al4(OH)4(PO4)4]: Its atomic arrangement and relationship to carminite, Pb2[Fe4(OH)4(AsO4)4]. American Mineralogist, 60 (5-6) 460-465
  4. 1987Cortesogno, L., Gaggero, L., Lucchetti, G. (1987) Phosphate mineralizations in a permo-triassic sequence (Giogo di Toirano, Italy). Neues Jahrbuch für Mineralogie, Monatshefte 1987: 305-313.
  5. 1993(1993) Acta Mineralogica Sinica 13(4), 346-353
