Betpakdalite-NaCa

[Na2(H2O)17Ca(H2O)6][Mo6+8As5+2Fe3+3O34(OH)3]
IMA status
  • Approved
IMA symbol
Bpd-NaCa
Also known as
  • IMA1971-057
  • Na Betpakdalit
  • Na Betpakdalite
  • +3 more

Where it forms, where it's found

Geological setting

Formed in the oxidation zone of a Mo–U deposit.

Type locality
Kyzylsai Mo-U deposit
  1. Chu-Ili Mountains
  2. Ulytau District
  3. Ulytau Region
  4. Kazakhstan

44.1167°, 73.1333°

2recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Colour
Lemon-yellow
Density
2.02 g/cm³

Optical

Optical type
Biaxial
Refractive index
1.792 – 1.81
Surface relief
Very high
Principal indices
nα 1.792 · nγ 1.81
Pleochroism
Visible

Distinct: X = pale yellow; Z = yellow Z > X

Dispersion
r > v perceptible
Michel-Lévy diagramhighlighted lineδ = 0.0180
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]180 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation180 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 19.41(3) Å · b = 11.12(4) Å · c = 15.26(3) Å
Cell angles
β = 131.13(7) °
Ratio a:b:c
1 : 0.573 : 0.786
Unit cell volume
2481 ų
Morphology

Pseudohexagonal crystals, very thin, platy, to several μ; as powdery aggregates, crusts, and films.

Type-locality form

Secondary mineral

Comment

Cell parameters from SCXRD-WPF (Kampf et al 2012)

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen6015.999959.940
44.03%
42MoMolybdenumMolybdenum895.950767.600
35.20%
26FeIronIron355.845167.535
7.68%
33AsArsenicArsenic274.922149.844
6.87%
1HHydrogenHydrogen491.00849.392
2.27%
11NaSodiumSodium222.99045.980
2.11%
20CaCalciumCalcium140.07840.078
1.84%
Total2180.369100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1971-057
  • Na Betpakdalit
  • Na Betpakdalite
  • Natriumbetpakdalit
  • Natrobetpakdalite
  • Sodium Betpakdalite

In other languages

German
Betpakdalit-NaCa · IMA 1971-057
Italian
Betpakdalite-NaCa · Natrobetpakdalite · Sodio-betpakdalite

Classification

Strunz
10th ed.

8.DM.15

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DMWith large and medium-sized cations, (OH, etc.):RO4 > 2:1Group
  • 8.DM.15Betpakdalite-NaCaSpecies
Dana
8th ed.

49.04.04.01

  • 49Hydrated Molybdates and TungstatesClass
  • 49.04Compound Molybdates and TungstatesType
  • 49.04.04— unnamed intermediate level —Group
  • 49.04.04.01Betpakdalite-NaCaSpecies
CIM

22.5.9

  • 22Phosphates, Arsenates or Vanadates with other AnionsClass
  • 22.5Phosphates, arsenates or vanadates with chromate, molybdate, niobate or tantalateGroup
  • 22.5.9Betpakdalite-NaCaSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1971Skvortsova K. V., Sidorenko, G. A., Nesterova, Y. S., Arapova, G. A., Dara, A. D., Rybakova, L. I. (1971) Sodium betpakdalite and conditions of its formation. Zapiski Vsesoyuznogo Mineralogicheskogo Obshchestva: 100 (5): 603-611.
  2. 1972Fleischer, Michael (1972) New Mineral Names. American Mineralogist, 57 (7-8) 1311-1317
  3. 1972Skvortsova, K.V. (1972) Sodium betpakdalite and conditions of its formation. International Geology Review, 14 (5) 473-480 doi:10.1080/00206817209475723DOI: 10.1080/00206817209475723
  4. 1999Cooper, M. A., Hawthorne, F. C. (1999) The crystal structure of betpakdalite, and a new chemical formula: {Mg(H2O)6}Ca2(H2O)13[Mo6+8As5+2Fe3+3O36(OH)](H2O)4. The Canadian Mineralogist, 37 (1) 61-66
  5. 2011Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2011) New minerals and nomenclature modifications approved in 2010, CNMNC Newsletter No 7. Mineralogical Magazine, 75 (1) 27-31 doi:10.1180/minmag.2011.075.1.27 DOI: 10.1180/minmag.2011.075.1.27
