Beusite-(Ca)

CaMn2+2(PO4)2
IMA status
  • Approved
IMA symbol
Beu-Ca
IMA approved
2017
Also known as
  • Beusiet-(Ca)
  • IMA2017-051

Where it forms, where it's found

Geological setting

A beryl–columbite–phosphate rare-element pegmatite

Type locality
Pegmatite between Upper Ross Lake and Redout Lake
  1. Yellowknife Pegmatite field
  2. Northwest Territories
  3. Canada

62.7436°, -113.1072°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Pale-brown
Streak
Very pale-brown
Tenacity
brittle
Density
3.610 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
1.685 – 1.7
Surface relief
High
Principal indices
nα 1.685 · nβ 1.688 · nγ 1.700
Pleochroism
Non-pleochroic

X || b; Y ˄ a = 40.3° in β obtuse; Z ˄ a = 49.7° in β acute.

Optical colour
Colourless in plane-polarized light
Notes

The optic axial angle is 46.0(5)°.

Michel-Lévy diagramhighlighted lineδ = 0.0150
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]150 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation150 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 8.799(2) Å · b = 11.724(2) Å · c = 6.170(1) Å
Cell angles
β = 99.23(3) °
Ratio a:b:c
1 : 1.332 : 0.701
Unit cell volume
628.3 ų
Z
4
Morphology

As lamellae 0.1–1.5 mm wide in tripylite

Type-locality form

As pale-brown lamellae 0.1–1.5 mm wide in triphylite

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen815.999127.992
37.66%
25MnManganeseManganese254.938109.876
32.33%
15PPhosphorusPhosphorus230.97461.948
18.22%
20CaCalciumCalcium140.07840.078
11.79%
Total339.894100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Beusiet-(Ca)
  • IMA2017-051

In other languages

German
Beusit-(Ca) · IMA 2017-051

Classification

Strunz
10th ed.

8.AB.20

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.APhosphates, etc. without additional anions, without H2ODivision
  • 8.ABWith medium-sized cationsGroup
  • 8.AB.20Beusite-(Ca)Species

Group, growth & confusion

In the same group
4 members

Literature, links & citation

Citations
  1. 2017Hålenius, U., Hatert, F., Pasero, M., Mills, S. J. (2017) New minerals and nomenclature modifications approved in 2017, CNMNC Newsletter No 39. Mineralogical Magazine, 81 (5) 1279-1286 doi:10.1180/minmag.2017.081.072DOI: 10.1180/minmag.2017.081.072
  2. 2018Hawthorne, Frank C., Wise, Michael A., Černý, Petr, Abdu, Yassir A., Ball, Neil A., Pieczka, Adam, Włodek, Adam (2018) Beusite-(Ca), ideally CaMn22+(PO4)2, a new graftonite-group mineral from the Yellowknife pegmatite field, Northwest Territories, Canada: Description and crystal structure. Mineralogical Magazine, 82 (6) 1323-1332 doi:10.1180/mgm.2018.120DOI: 10.1180/mgm.2018.120
  3. 2020(2020) Beusite-(Ca). Handbook of Mineralogy. Mineralogical Society of America
