Bixbyite-(Mn)

Mn3+2O3
IMA status
  • Approved
  • Grandfathered
IMA symbol
Bxb
Discovered
1897
Also known as
  • Bixbyiet-(Mn)
  • Bixbyit
  • Bixbyita
  • +8 more

Where it forms, where it's found

Geological setting

In lithophysal cavities in rhyolite.

In rhyolites; in metamorphosed manganese ores.

Type locality
Maynard's Mine
  1. Pismire Knolls
  2. Thomas Range
  3. Juab County
  4. Utah
  5. USA

39.7741°, -113.0890°

119recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106 – 6.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Black
Streak
Black
Cleavage
Imperfect/Fair

on (111), in traces

Fracture
Irregular/Uneven
Density
4.945 g/cm³

Optical

Optical type
Isotropic
Tropism
Isotropic
Reflectance R%
(24.7) 400 nm, (24.1) 420 nm, (23.5) 440 nm, (23.0) 460 nm, (22.8) 480 nm, (22.9) 500 nm, (23.3) 520 nm, (23.6) 540 nm, (23.5) 560 nm, (23.2) 580 nm, (22.9) 600 nm, (22.7) 620 nm, (22.4) 640 nm, (22.2) 660 nm, (22.2) 680 nm, (22.1) 700 nm
Reflected-light panel
23.1 %isotropic · single curve
Specimen sRGB 175, 123, 66
White reference100 % reflector under same lamp

Crystallography

Crystal system
Isometric
Space group
#202
Cell parameters
a = 9.411 Å
Z
16
Morphology

Cubes, rarely modified by (112) or (111), commonly striated and occasionally deeply pitted, to 6 cm; also massive.

Twinning

On (111), as penetration twins.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
25MnManganeseManganese254.938109.876
69.60%
8OOxygenOxygen315.99947.997
30.40%
Total157.873100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Mg
  • Si
  • Ti

Synonyms

  • Bixbyiet-(Mn)
  • Bixbyit
  • Bixbyita
  • Bixbyite
  • Manganbixbyit
  • Manganbixbyita
  • Manganbixbyite
  • Partridgeite
  • Sitaparit
  • Sitaparita
  • Sitaparite

In other languages

German
Bixbyit · Bixbyit- · Bixbyit-(Mn) · Partridgeit · Sitaparit

Classification

Strunz
10th ed.

4.CB.10

  • 4OxidesClass
  • 4.CMetal: Oxygen = 2: 3,3: 5, and similarDivision
  • 4.CBWith medium-sized cationsGroup
  • 4.CB.10Bixbyite-(Mn)Species
Dana
8th ed.

04.03.07.02

  • 04Simple OxidesClass
  • 04.03A2X3Type
  • 04.03.07— unnamed intermediate level —Group
  • 04.03.07.02Bixbyite-(Mn)Species
CIM

7.19.1

  • 7Oxides and HydroxidesClass
  • 7.19Oxides of Mn and FeGroup
  • 7.19.1Bixbyite-(Mn)Species

Group, growth & confusion

Often grow together
2 minerals

Literature, links & citation

Citations
  1. 1897Penfield, S.L. and Foote, H.W. (1897) On bixbyite, a new mineral, and notes on the associated topaz. American Journal of Science: 4: 105-108.
  2. 1897Penfleld, S.L.; Poote, H.W. (1897) Ueber Bixbyit, ein neues Mineral, mit einer Notiz über den begleitenden Topas. Zeitschrift für Kristallographie, 28 (1-6). 592-595 doi:10.1524/zkri.1897.28.1.592DOI: 10.1524/zkri.1897.28.1.592
  3. 1909Fermor, L.L. (1909) Geological Survey of India, Rec.: 37: 199.
  4. 1909Fermor, Lewis Leigh (1909) The manganese ore deposits of India. Memoirs of the Geological Survey of India Vol. 37. Geological Survey of India
  5. 1930Pauling, L., Shappell, M.D. (1930) The Crystal Structure of Bixbyite and the C-Modification of the Sesquioxides. Zeitschrift für Kristallographie: 75(1): 128-142.
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Bixbyite-(Mn) — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/bixbyite-mn-691},
  note      = {Accessed 2026-05-11}
}
