Braunite

Mn2+Mn3+6O8(SiO4)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Bnt
Discovered
1827
Also known as
  • Brachytypous Manganese-Ore
  • Braunit-I
  • Braunite (of Haidinger)
  • +10 more

Where it forms, where it's found

Geological setting

Metamorphism of manganese silicates and weathering product.

Type locality
Oehrenstock
  1. Langewiesen
  2. Ilmenau
  3. Ilm District
  4. Thuringia
  5. Germany

50.6600°, 10.9442°

419recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106 – 6.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Brownish black · steel-grey
Streak
Black
Tenacity
brittle
Cleavage
Perfect

(112) perfect.

Fracture
Irregular/Uneven · Sub-Conchoidal
Density
4.72 g/cm³

Optical

Optical colour
Grayish white with a brownish tinge.
Anisotropism
Weak in air, distinct in oil - dark to lighter slate gray.
Tropism
Anisotropic
Reflectance R%
(23.4,25.4) 400, (22.7,24.5) 420, (22.0,23.6) 440, (21.5,22.9) 460, (21.0,22.4) 480, (20.5,21.9) 500, (20.0,21.5) 520, (19.6,21.2) 540, (19.3,20.9) 560, (19.0,20.6) 580, (18.8,20.3) 600, (18.6,20.0) 620, (18.5,19.8) 640, (18.3,19.6) 660, (18.2,19.5) 680, (18.1,19.4) 700
Reflected-light panel
20.0 %anisotropic · dual curve
Specimen sRGB 159, 113, 66
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Weak in air, distinct in oil - dark to lighter slate gray.
Reflected colour
Grayish white with a brownish tinge.

Crystallography

Crystal system
Tetragonal
Space group
#177
Cell parameters
a = 9.432 Å · c = 18.703 Å
Z
8
Morphology

Pyramidal (011) and (131); pseudo-octahedral. Striated on (001) and (201) parallel to [010]. Granular massive.

Twinning

On (112) producing a combination with only a small reentrant angle (0°18') on е(011).

Comment

Cell from de Villiers (1975). Cell dimensions variable: a = 9.36-9.45, c = 18.60-18.97 Å.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
25MnManganeseManganese754.938384.566
63.60%
8OOxygenOxygen1215.999191.988
31.75%
14SiSiliconSilicon128.08528.085
4.65%
Total604.639100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Ca
  • B
  • Ba
  • Ti
  • Al
  • Mg

Synonyms

  • Brachytypous Manganese-Ore
  • Braunit-I
  • Braunite (of Haidinger)
  • Braunite-I
  • Hartbraunstein
  • Heteroclase
  • Heteroclin
  • Heteroklin
  • Leptonematite (of Adam)
  • Marceline
  • Pesillit
  • Pesillita
  • Pesillite

In other languages

French
Braunite
German
Braunit
Spanish
Braunita · Pesillita
Italian
Braunite · Braunite-I
Japanese
ブラウン鉱
Chinese
褐錳礦 · 褐锰矿
Russian
браунит
Arabic
براونيت

Classification

Strunz
10th ed.

9.AG.05

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AGNesosilicates with additional anions; cations in > [6] +- [6] coordinationGroup
  • 9.AG.05BrauniteSpecies
Dana
8th ed.

07.05.01.03

  • 07Multiple OxidesClass
  • 07.05(AB)2X3Type
  • 07.05.01Humite group (Tetragonal: I41/acd) containing SiGroup
  • 07.05.01.03BrauniteSpecies
CIM

14.17.3

  • 14Silicates not Containing AluminumClass
  • 14.17Silicates of MnGroup
  • 14.17.3BrauniteSpecies

Group, growth & confusion

In the same group
4 members
Often grow together
5 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1827Haidinger, W. (1827): On the crystalline Forms and Properties of the Manganese Ores.- Edinburgh Journal of Science, IV, 41
  2. 1828Haidinger, W. (1828): Mineralogische Beschreibung der Manganerze. I. Prismatoïdisches Manganerz, Manganit. II. Pyramidales Manganerz, Hausmannit. III. Untheilbares Manganerz, Psilomelan. IV. Brachytypes Manganerz, Braunit. V. Prismatisches Manganerz, Pyrolusit.- Poggendorffs Annalen der Physik und Chemie 14, 197-211
  3. 1831Turner, E. (1831): Chemical Examination of the Oxides of Manganese.- Transactions of the Royal Society of Edinburgh, Vol. II, 143-174
  4. 1840Breithaupt in Evreinov (1840), Ann. Phys.: 49: 204.
  5. 1938Switzer, George (1938) Crystallography of braunite from Nagpur, India. American Mineralogist, 23 (10) 649-653
