Bonacinaite

Sc(AsO4) · 2H2O
IMA status
  • Approved
IMA symbol
Bci
IMA approved
2018
Also known as
  • Bonacinaiet
  • IMA2018-056
  • UM2005-02-AsO:AlHPScSi

Where it forms, where it's found

Geological setting

an old manganese mine, where it occurs as a low-temperature hydrothermal mineral

Type locality
Varenche Mine
  1. Saint-Barthélemy
  2. Nus
  3. Aosta Valley
  4. Italy

45.7893°, 7.4882°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
colourless (with faint to distinct violet tints)
Streak
white
Tenacity
brittle
Density
2.82 g/cm³

Optical

Optical type
Biaxial (-) · 2V calc = -88.9°
Refractive index
1.598 – 1.638
Surface relief
Moderate
Principal indices
nα 1.598 · nβ 1.618 · nγ 1.638
Pleochroism
Weak

X is colourless to light grey, Y is light violet and Z is light violet

UV response
none
Michel-Lévy diagramhighlighted lineδ = 0.0400
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]400 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation400 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 5.533(1) Å · b = 10.409(2) Å · c = 9.306(2) Å
Cell angles
β = 91.94(3) °
Ratio a:b:c
1 : 1.881 : 1.682
Z
4
Twinning

none

Type-locality form

pseudohexagonal, thick tabular crystals, up to 0.25 mm in size, sometimes with annular internal zones showing violet tinges, or as small, faintly violet lath-shaped crystals

Comment

Space group is P21/n

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen615.99995.994
43.65%
33AsArsenicArsenic174.92274.922
34.07%
21ScScandiumScandium144.95644.956
20.44%
1HHydrogenHydrogen41.0084.032
1.84%
Total219.904100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Bonacinaiet
  • IMA2018-056
  • UM2005-02-AsO:AlHPScSi

In other languages

German
Bonacinait · IMA 2018-056

Classification

Strunz
10th ed.

8.CD.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CDWith only medium-sized cations, RO4:H2O = 1:2Group
  • 8.CD.05BonacinaiteSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 2005Barresi, A.A., Kolitsch, U., Ciriotti, M.E., Ambrino, P., Bracco, R., Bonacina, E. (2005) La miniera di manganese di Varenche (Aosta, Italia nord-occidentale): ardennite, arseniopleite, manganberzeliite, pirofanite, sarkinite, thortveitite, nuovo As-Sc-analogo della metavariscite e altre specie. Micro (località): 2/2005: 81-122. https://www.academia.edu/51571167/La_miniera_di_manganese_di_Varenche_Aosta_Italia_nord_occidentale_ardennite_arseniopleite_manganberzeliite_pirofanite_sarkinite_thortveitite_nuovo_As_Sc_analogo_della_metavariscite_e_altre_specie
  2. 2018Hålenius, U., Hatert, F., Pasero, M., Mills, S. J. (2018) CNMNC Newsletter 45, New minerals and nomenclature modifications approved in 2018. Mineralogical Magazine, 82 (5) 1225-1232 doi:10.1180/mgm.2018.160DOI: 10.1180/mgm.2018.160
  3. 2020Kolitsch, Uwe, Weil, Matthias, Kovrugin, Vadim M., Krivovichev, Sergey V. (2020) Crystal chemistry of the variscite and metavariscite groups: Crystal structures of synthetic CrAsO4⋅2H2O, TlPO4⋅2H2O, MnSeO4⋅2H2O, CdSeO4⋅2H2O and natural bonacinaite, ScAsO4⋅2H2O. Mineralogical Magazine, 84 (4) 568-583 doi:10.1180/mgm.2020.57DOI: 10.1180/mgm.2020.57
  4. 2022(2022) Bonacinaite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2024Ciriotti, Marco E., Kolitsch, Uwe, Cámara, Fernando, Vignola, Pietro, Hatert, Frédéric, Bittarello, Erica, Bracco, Roberto, Bortolozzi, Giorgio Maria (2024) Bonacinaite, Sc(AsO4)  ⋅  2H2O, the first scandium arsenate. European Journal of Mineralogy, 36 (5). 863-872 doi:10.5194/ejm-36-863-2024DOI: 10.5194/ejm-36-863-2024
