Boothite

Cu(SO4) · 7H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Boo
Discovered
1903
Also known as
  • Boothiet
  • Boothite (of Schaller)
  • Copper-Melanterite

Where it forms, where it's found

Geological setting

Zone of oxidation.

Type locality
Alma Mine
  1. Leona Heights deposit
  2. Leona Heights
  3. Oakland
  4. Oakland Hills (San Leandro Hills)
  5. Alameda County
  6. California
  7. USA
19recorded occurrences
Source · OpenStreetMap

Varieties

Physical

Hardness
123456789102 – 2.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Light blue · light blue in transmitted light
Tenacity
brittle
Cleavage
Imperfect/Fair

On (001) imperfect.

Fracture
Irregular/Uneven
Density
1.94 g/cm³

Optical

Optical type
Biaxial (+/-)
Refractive index
1.47 – 1.49
Surface relief
Low
Principal indices
nα 1.47 · nβ 1.48 · nγ 1.49
Dispersion
relatively weak
Extinction
Y = b; X ≃ c.
Notes

2V(meas.) = Large

Michel-Lévy diagramhighlighted lineδ = 0.0200
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]200 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation200 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 14.190(10) Å · b = 6.537(2) Å · c = 10.825(6) Å
Cell angles
α = 106.02(5) °
Ratio a:b:c
1 : 0.461 : 0.763
Morphology

Crystals rare. Commonly massive with crystalline or fibrous structure.

Type-locality form

Fibrous or crystalline massive.

Comment

Cell parameters and space group from Leverett et al. (2004).

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1115.999175.989
61.60%
29CuCopperCopper163.54663.546
22.24%
16SSulfurSulfur132.06032.060
11.22%
1HHydrogenHydrogen141.00814.112
4.94%
Total285.707100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Boothiet
  • Boothite (of Schaller)
  • Copper-Melanterite

In other languages

French
Boothite
German
Boothit
Italian
Boothite
Chinese
七水胆矾
Arabic
بوثيت

Classification

Strunz
10th ed.

7.CB.35

  • 7SulfatesClass
  • 7.CSulfates (selenates, etc.) without additional anions, with H2ODivision
  • 7.CBWith only medium-sized cationsGroup
  • 7.CB.35BoothiteSpecies
Dana
8th ed.

29.06.10.02

  • 29Hydrated Acid and Normal SulfatesClass
  • 29.06AXO4·xH2OType
  • 29.06.10Melanterite Group (Heptahydrates, Monoclinic: P21/c)Group
  • 29.06.10.02BoothiteSpecies
CIM

25.2.4

  • 25SulphatesClass
  • 25.2Sulphates of Cu and AgGroup
  • 25.2.4BoothiteSpecies

Group, growth & confusion

In the same group
5 members

Literature, links & citation

Citations
  1. 1903Schaller, Waldemar Theodore (1903) Minerals from Leona Heights, Alameda County, California. University of California, Department of Geological Sciences Bulletin: 3: 191-217.
  2. 1904Schaller, W.T. (1904) Notes on some California minerals. American Journal of Science: s4-17(99): 191-194 (192).
  3. 1910Lacroix, A. (1910) Minéralogie de la France et de ses colonies Vol. 4. Library Polytechnique, Paris.
  4. 1934Larsen, E.S.; Berman, H. (1934) The microscopic determination of the nonopaque minerals. Bulletin of the US Geological Survey Vol. 848. US Geological Survey p.1-266. doi:10.3133/b848 DOI: 10.3133/b848
  5. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
