Brandtite

Ca2Mn2+(AsO4)2 · 2H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Bdt
Discovered
1888
Also known as
  • Brandtiet

Where it forms, where it's found

Type locality
Harstigen Mine
  1. Pajsberg
  2. Persberg ore district
  3. Filipstad
  4. Värmland County
  5. Sweden

59.7853°, 14.3139°

24recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colourless · white · pink · colourless in transmitted light.
Tenacity
brittle
Cleavage
Perfect

On (010), perfect.

Density
3.67 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 22 – 24° · 2V calc = 38 – 60°
Refractive index
1.707 – 1.729
Surface relief
High
Principal indices
nα 1.707 – 1.709 · nβ 1.711 · nγ 1.724 – 1.729
Birefringence
0.018
Dispersion
r < v strong
UV response
Not known to be fluorescent.
Michel-Lévy diagramhighlighted lineδ = 0.0180
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]180 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation180 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#14
Cell parameters
a = 5.899 Å · b = 12.968 Å · c = 5.684 Å
Cell angles
β = 108.05 °
Ratio a:b:c
1 : 2.198 : 0.964
Z
2
Morphology

Crystals stout prismatic [001]. (100) striated [001]. Frequently grouped into radiated groups. Rounded or reniform masses with a radial-fibrous structure.

Twinning

On (100), common.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1015.999159.990
35.63%
33AsArsenicArsenic274.922149.844
33.38%
20CaCalciumCalcium240.07880.156
17.85%
25MnManganeseManganese154.93854.938
12.24%
1HHydrogenHydrogen41.0084.032
0.90%
Total448.960100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Brandtiet

In other languages

German
Brandtit
Italian
Brandtite

Classification

Strunz
10th ed.

8.CG.10

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CGWith large and medium-sized cations, RO4:H2O = 1:1Group
  • 8.CG.10BrandtiteSpecies
Dana
8th ed.

40.02.03.02

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.02AB2(XO4)2·xH2OType
  • 40.02.03Roselite Subgroup (Monoclinic: P21/c)Group
  • 40.02.03.02BrandtiteSpecies
CIM

20.8.14

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.8Arsenates of MnGroup
  • 20.8.14BrandtiteSpecies

Group, growth & confusion

In the same group
6 members
Often grow together
1 mineral
Commonly confused with
3 minerals

Literature, links & citation

Citations
  1. 1888Nordenskiöld (1888) Svenska Vetenskapsakademien, Stockholm, Handlingar [Ak. Stockholm Öfv.]: 45: 418.
  2. 1891Lindström (1891) Geologiska Föeningens I Stockholm. Förhandlinger, Stockholm: 13L: 123 (Nordenskiöld description in).
  3. 1892Dana, Edward Salisbury; Dana, James Dwight (1892) A System of Mineralogy (6th ed.). John Wiley & Sons, Inc.
  4. 1913(1913) Atlas Der Krystallformen Vol. 1 - Text - Band I - Adamin-Buntkupfererz. Carl Winters Universitätsbuchhandlung, Heidelberg.
  5. 1919Aminoff (1919) Geologiska Föeningens I Stockholm. Förhandlinger, Stockholm: 41: 161.
