Calcinaksite

KNaCa(Si4O10) · H2O
IMA status
  • Approved
IMA symbol
Cnk
IMA approved
2013
Also known as
  • Calcinaksiet
  • IMA2013-081

Where it forms, where it's found

Geological setting

A xenolith of metamorphosed carbonate-rich rock in an alkaline magma

Type locality
Bellerberg volcano
  1. Vordereifel
  2. Mayen-Koblenz
  3. Rhineland-Palatinate
  4. Germany

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Colorless to light gray
Tenacity
brittle
Cleavage
Perfect

perfect on (001) and less perfect on (010)

Density
2.62 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 75°
Refractive index
1.542 – 1.565
Surface relief
Moderate
Principal indices
nα 1.542 · nβ 1.550 · nγ 1.565
Dispersion
medium, r<v.
UV response
None
Michel-Lévy diagramhighlighted lineδ = 0.0230
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]230 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation230 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
P-1
Cell parameters
a = 7.021(2) Å · b = 8.250(3) Å · c = 10.145(2) Å
Cell angles
α = 102.23(2) ° · β = 100.34(2) ° · γ = 115.09(3) °
Ratio a:b:c
1 : 1.175 : 1.445
Z
2
Type-locality form

Clusters of colourless to light-grey subhedral prismatic crystals

Comment

P1¯

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1115.999175.989
44.84%
14SiSiliconSilicon428.085112.340
28.62%
20CaCalciumCalcium140.07840.078
10.21%
19KPotassiumPotassium139.09839.098
9.96%
11NaSodiumSodium122.99022.990
5.86%
1HHydrogenHydrogen21.0082.016
0.51%
Total392.511100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Calcinaksiet
  • IMA2013-081

In other languages

German
Calcinaksit · IMA 2013-081
Italian
calcinaksite

Classification

Strunz
10th ed.

9.DG

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DGInosilicates with 3-periodic single and multiple chainsGroup
  • 9.DGCalcinaksiteSpecies

Group, growth & confusion

In the same group
4 members

Literature, links & citation

Citations
  1. 2013Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2013) New minerals and nomenclature modifications approved in 2013. CNMNC Newsletter No 18. Mineralogical Magazine, 77 (8) 3249-3258 doi:10.1180/minmag.2013.077.8.15DOI: 10.1180/minmag.2013.077.8.15
  2. 2014Aksenov, Sergey M., Rastsvetaeva, Ramiza K., Chukanov, Nikita V., Kolitsch, Uwe (2014) Structure of calcinaksite KNa[Ca(H2O)][Si4O10], the first hydrous member of the litidionite group of silicates with [Si8O20]8−tubes. Acta Crystallographica Section B Structural Science, Crystal Engineering and Materials, 70 (4). 768-775 doi:10.1107/s2052520614012992DOI: 10.1107/s2052520614012992
  3. 2016(2016) Calcinaksite. Handbook of Mineralogy. Mineralogical Society of America
