Manaksite

KNaMn2+Si4O10
IMA status
  • Approved
IMA symbol
Mnk
Discovered
1992
Also known as
  • Manaksiet

Where it forms, where it's found

Geological setting

Ultra-agpaitic pegmatites.

Type locality
Alluaiv Mountain
  1. Lovozersky District
  2. Murmansk Oblast
  3. Russia

67.8645°, 34.5124°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colourless · cream · light rose
Streak
White
Tenacity
brittle
Cleavage
Perfect

(001), perfect; (010), less perfect

Fracture
Hackly
Density
2.73 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 73°
Refractive index
1.54 – 1.557
Surface relief
Moderate
Principal indices
nα 1.540 · nβ 1.551 · nγ 1.557
Dispersion
weak
Michel-Lévy diagramhighlighted lineδ = 0.0170
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]170 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation170 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 6.993(5) Å · b = 8.219(7) Å · c = 10.007(9) Å
Cell angles
α = 105.11(7) ° · β = 100.76(6) ° · γ = 114.79(6) °
Ratio a:b:c
1 : 1.175 : 1.431
Z
2
Type-locality form

Grains, to 3 mm, and aggregates, to 5 mm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1015.999159.990
41.09%
14SiSiliconSilicon428.085112.340
28.85%
25MnManganeseManganese154.93854.938
14.11%
19KPotassiumPotassium139.09839.098
10.04%
11NaSodiumSodium122.99022.990
5.91%
Total389.356100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Sr
  • Ca
  • Mg
  • Fe

Synonyms

  • Manaksiet

In other languages

German
IMA 1990-024 · Manaksit
Italian
manaksite

Classification

Strunz
10th ed.

9.DG.70

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DGInosilicates with 3-periodic single and multiple chainsGroup
  • 9.DG.70ManaksiteSpecies
Dana
8th ed.

70.01.01.03

  • 70Inosilicates Column or Tube StructuresClass
  • 70.01Column or Tube Structures with columnar silicate unitsType
  • 70.01.01Litidionite groupGroup
  • 70.01.01.03ManaksiteSpecies

Group, growth & confusion

In the same group
4 members

Literature, links & citation

Citations
  1. 1992Khomyakov, A. P., Kurova, T. A., Nechelyustov, G. N. (1992) Manaksite NaKMnSi4O10: a new mineral. Zapiski Vserossijskogo Mineralogicheskogo Obshchestva, 121 (1) 112-114
  2. 1993Jambor, John L., Vanko, David A. (1993) New Mineral Names. American Mineralogist, 78 (11-12) 1314-1319
  3. 1997Mandarino, Joseph A. (1997) New Minerals 1990-1994. The Mineralogical Record Inc., Tuscon, Arizona. 220pp.
  4. 2001(2001) Manaksite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2008Karimova, O., Burns, P. C. (2008): Silicate tubes in the crystal structure of manaksite. Pp. 153-156 in: Krivovichev, S. V. , Ed. (2008): Minerals as Advanced Materials I. Springer, 256 pp.
