Chabazite-Sr

(Sr,Ca)2[Al4Si8O24] · 11H2O
IMA status
  • Approved
IMA symbol
Cbz-Sr
Also known as
  • Chabasita-Sr
  • IMA1999-040

Where it forms, where it's found

Geological setting

In thin aegirine-potassic-fe1dspar pegmatite crosscutting nepheline and noseane syenites.

Type locality
Seidozeritovyi pegmatite no. 1
  1. Suoluaiv Mountain
  2. Lovozersky District
  3. Murmansk Oblast
  4. Russia
6recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104 – 4.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Colour
Colourless · yellowish
Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

On (101)

Fracture rough

Density
2.16 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.503 – 1.507
Surface relief
Moderate
Principal indices
nω 1.503 · nε 1.507
Michel-Lévy diagramhighlighted lineδ = 0.0040
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]40 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation40 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#99
Cell parameters
a = 13.715(6) Å · c = 15.09(1) Å
Unit cell volume
2458 ų
Morphology

Disc-like "phacolite"-type crystals.

Twinning

Phacolite-type twinning

Type-locality form

Crystals, to 0.3 mm. Coarse-shaped disk-like, twinned as in phacolite.

Comment

Data for type material.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3515.999559.965
47.85%
14SiSiliconSilicon828.085224.680
19.20%
38SrStrontiumStrontium287.620175.240
14.98%
13AlAluminiumAluminium426.982107.928
9.22%
20CaCalciumCalcium240.07880.156
6.85%
1HHydrogenHydrogen221.00822.176
1.90%
Total1170.145100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Chabasita-Sr
  • IMA1999-040

In other languages

German
Chabasit-Sr · IMA 1999-040
Italian
cabasite-Sr · IMA1999-040

Classification

Strunz
10th ed.

9.GD.10

  • 9SilicatesClass
  • 9.GTektosilicates with zeolitic H2O; zeolite familyDivision
  • 9.GDChains of 6-membered rings – tabular zeolitesGroup
  • 9.GD.10Chabazite-SrSpecies

Group, growth & confusion

In the same group
4 members

Literature, links & citation

Citations
  1. 1982Alberti, A., Galli, E., Vezzalini, G., Passaglia, E., Zanazzi, P.F. (1982) Position of cations and water molecules in hydrated chabazite. Natural and Na-, Ca-, Sr- and K-exchanged chabazites. Zeolites, 2 (4) 303-309 doi:10.1016/s0144-2449(82)80075-4DOI: 10.1016/s0144-2449(82)80075-4
  2. 2000Pekov, I.V., Turchkova, A.G., Chukanov, N.V., Zadov, A.E. and Grishin, B.G. (2000) Chabazite-Sr (SrCa)[Al2Sr4O12]•6H2O – new zeolite from the Lovozero massif. Zapiski Vserossiyskogo Mineralogicheskogo Obshchestva: 129: 54-58.
  3. 2000Pekov, I.V., Turchkova, A.G., Chukanov, N.V., Zadov, A.E. and Grishin, B.G. (2000) Chabazite-Sr (SrCa)[Al2Sr4O12]•6H2O – new zeolite from the Lovozero massif. Zapiski Vserossiyskogo Mineralogicheskogo Obshchestva: 129: 54-58 (in Russian)
  4. 2003Neuhoff, Philip S., Stebbins, Jonathan F., Bird, Dennis K. (2003) Si-Al disorder and solid solutions in analcime, chabazite, and wairakite. American Mineralogist, 88 (2) 410-423 doi:10.2138/am-2003-2-317DOI: 10.2138/am-2003-2-317
  5. 2021(2021) Chabazite-Sr. Handbook of Mineralogy. Mineralogical Society of America
