Chabournéite

AgzTl8-x-zPb4+2xSb40-x-yAsyS68 (with 0.00 ≤ x ≤ 0.40, 16.15 ≤ y ≤ 19.11, 0.04 ≤ z ≤ 0.11)
IMA status
  • Approved
IMA symbol
Chb
IMA approved
1976
Also known as
  • Chabournéiet
  • IMA1976-042
  • Shaburneite

Where it forms, where it's found

Geological setting

Fracture fillings in dolomitic limestones.

Hydrothermal veins in dolomites.

Type locality
Jas Roux
  1. La Chapelle-en-Valgaudemar
  2. Gap
  3. Hautes-Alpes
  4. Provence-Alpes-Côte d'Azur
  5. France

44.8125°, 6.3217°

4recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103 – 3.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Black
Streak
Red, brown
Fracture
Conchoidal
Density
5.104 g/cm³

Optical

Pleochroism
Weak
Optical colour
White
Anisotropism
Strong in bluish and greenish colors
Internal reflections
Red
Tropism
Anisotropic
Reflectance R%
(33.8,39.7) 400, (33.5,39.1) 420, (33.2,38.6) 440, (32.8,37.9) 460, (32.3,37.2) 480, (32.0,36.6) 500, (31.7,36.1) 520, (31.4,35.6) 540, (31.1,34.9) 560, (30.7,34.3) 580, (30.3,33.7) 600, (29.7,33.0) 620, (29.1,32.2) 640, (28.5,31.6) 660, (27.9,30.9) 680, (27.3,30.3) 700
Reflected-light panel
31.0 %anisotropic · dual curve
Specimen sRGB 197, 141, 80
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Strong in bluish and greenish colors
Reflected colour
White
Internal reflections
Red

Crystallography

Crystal system
Triclinic
Space group
#1
Cell parameters
a = 16.346(5) Å · b = 42.602(10) Å · c = 8.543(3) Å
Cell angles
α = 95.86(3) ° · β = 86.91(3) ° · γ = 96.88(3) °
Ratio a:b:c
1 : 2.606 : 0.523
Z
1
Morphology

Crystals to 1 mm.

Type-locality form

Very imperfect millimetric crystals. Aggregates, intimately associated with realgar and pierrotite reaching centimetric dimensions.

Comment

Bonaccorsi et al. (2010) give P-1 and different cell: a 8.150(2), b 8.716(2), c 21.579(4) Å, α 85.18(1)°, β 96.94(1)°, γ 88.60(1)°, V = 1515(1) Å3. This phase later became protochabournéite. For Pb-rich chabournéite (empirical EPMA-derived formula: Ag0.04(1)Tl2.15(2)Pb0.64(1)Sb5.12(1)As5.05(1)S17.32(5)), Biagioni et al. (2015) give a = 8.5197(4), b = 42.461(2), c = 16.293(8) Å, α = 83.351(2), β = 90.958(2), γ = 84.275(2)°, V = 5823(3) Å3.

Crystal structure

Synonyms

  • Chabournéiet
  • IMA1976-042
  • Shaburneite

In other languages

German
Chabournéit · IMA 1976-042
Italian
Chabournéite

Classification

Strunz
10th ed.

2.HD.05e

  • 2Sulfides and SulfosaltsClass
  • 2.HSulfosalts of SnS archetypeDivision
  • 2.HDWith TlGroup
  • 2.HD.05eChabournéiteSpecies
Dana
8th ed.

03.08.12.01

  • 03SulfosaltsClass
  • 03.081 < ø < 2Type
  • 03.08.12— unnamed intermediate level —Group
  • 03.08.12.01ChabournéiteSpecies
CIM

5.5.20

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.5Sulpharsenites etc. of TlGroup
  • 5.5.20ChabournéiteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1977Picot, P. and Johan, Z. (1977) Atlas des Minéraux Métalliques. Atlas des Minéraux Métalliques. Mémoires du Bureau de Recherches Géologiques et Minières: 90, 406 pp.
  2. 1979Nagl, A. (1979) The crystal structure of a thallium sulfosalt, Tl8Pb4Sb21As19S68. Zeitschrift für Kristallographie, 150 (1-4). 85-106 doi:10.1524/zkri.1979.150.1-4.85 DOI: 10.1524/zkri.1979.150.1-4.85
  3. 1979Fleischer, Michael, Chao, George Y., Pabst, and Adolf (1979) New Mineral Names. American Mineralogist, 64 (1-2) 241-245
  4. 1981Johan, Zdenek, Mantienne, Joseph, Picot, Paul (1981) La chabournéite, un nouveau minéral thallifère. Bulletin de Minéralogie, 104 (1) 10-15 doi:10.3406/bulmi.1981.7538 DOI: 10.3406/bulmi.1981.7538
  5. 1982Fleischer, M., Cabri, L.J., Chao, G.Y., Mandarino, J.A., Pabst, A. (1982) New mineral names. American Mineralogist: 67: 621-624.
