Chevkinite-(Ce)

Ce4(Ti,Fe2+,Fe3+)5O8(Si2O7)2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Cvk-Ce
Discovered
1839
Also known as
  • Chevkiniet-(Ce)
  • Tscheffkinit-(Ce)
  • Tscheffkinite-(Ce)

Where it forms, where it's found

Geological setting

Aegirine-quartz-feldspar pegmatites.

Type locality
Pit No. 17
  1. Ilmen Mountains
  2. Chelyabinsk Oblast
  3. Russia
104recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 5.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Earthy
Colour
Black

Red to orange-brown inner reflections

Tenacity
brittle
Fracture
Conchoidal
Density
4.53 g/cm³

Optical

Optical type
Biaxial (-)
Refractive index
1.967 – 2.05
Surface relief
Very high
Principal indices
nα 1.967 – 1.973 · nβ 2.02 · nγ 2.05
Dispersion
r < v; distinct to strong
Extinction
Z ∧ c = 11°-26°.
Notes

Absorption: Z > Y > X.

Michel-Lévy diagramhighlighted lineδ = 0.0800
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]800 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation800 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/a
Cell parameters
a = 13.370(3) Å · b = 5.660(2) Å · c = 11.280(3) Å
Cell angles
β = 100.87(3) °
Ratio a:b:c
1 : 0.423 : 0.844
Z
2
Twinning

Twin plane (001).

Type-locality form

Crystals up to 5 cm.

Comment

Some material is metamict.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
58CeCeriumCerium4140.116560.464
30.75%
26FeIronIron1055.845558.450
30.64%
8OOxygenOxygen2215.999351.978
19.31%
22TiTitaniumTitanium547.867239.335
13.13%
14SiSiliconSilicon428.085112.340
6.17%
Total1822.567100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ca
  • Nb
  • Mg
  • Th
  • Sr
  • Zr

Synonyms

  • Chevkiniet-(Ce)
  • Tscheffkinit-(Ce)
  • Tscheffkinite-(Ce)

In other languages

German
Chevkinit-(Ce) · Tschewkinit
Italian
Chevkinite- · Chevkinite-(Ce)
Chinese
硅钛铈铁矿
Russian
чевкинит

Classification

Strunz
10th ed.

9.BE.70

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BESi2O7 groups, with additional anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BE.70Chevkinite-(Ce)Species
Dana
8th ed.

56.02.08.01

  • 56Sorosilicates Si2o7 Groups, with Additional O, Oh, F and H2oClass
  • 56.02Si2O7 Groups and O, OH, F, and H2O with cations in [4] and/or >[4] coordinationType
  • 56.02.08Perierite - Chevkinite groupGroup
  • 56.02.08.01Chevkinite-(Ce)Species

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. Bagiński, B., Macdonald, R., Stachowicz, M., Jokubauskas, P., Kotowski, J,. Matyszczak, W., Harlov, D. (2023): Growth of ThSiO4 phases during experiments as a result of interaction of hydrothermal fluids with chevkinite-(Ce): element mobility, textural features and variable crystal structure. 9th Meeting of the Mineralogical Society of Poland / 28th Meeting of the Petrology group of the Mineralogical Society of Poland, "Oceanic lithosphere: rocks, minerals, and critical resources", October 19-22, Bielawa, Poland. Mineralogia - Special Papers, 51, 36.
  2. 1842Rose, G. (1842) 38. Tschewkinit. Mineralogisch-Geognostische Reise nach dem Ural, dem Altai und dem Kaspischen Meere, 2, 513-514.
  3. 1928Foshag, W.F. (1928) New mineral names. American Mineralogist: 13: 491-494.
  4. 1966Bonatti, S., Gottardi, G. (1966) Un caso di polimorfismo a strati in sorosilicati: perrierite e chevkinite. Periodico di Mineralogia – Roma pp. 69-91.
  5. 1967Ito, Jun (1967) A study of chevkinite arid perrierite. American Mineralogist, 52 (7-8) 1094-1104
