Dingdaohengite-(Ce)

(Ce,La)4Fe2+(Ti,Fe2+,Mg,Fe3+)2Ti2Si4O22
IMA status
  • Approved
IMA symbol
Ddh-Ce
IMA approved
2005
Also known as
  • Dingdaohengiet-(Ce)
  • IMA2005-014

Where it forms, where it's found

Type locality
Bayan Obo deposit
  1. Bayan Obo mining district
  2. Baotou City
  3. Inner Mongolia
  4. China

41.7958°, 109.9694°

7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent · Opaque
Colour
black
Streak
brown
Tenacity
brittle
Fracture
Conchoidal
Density
4.83 g/cm³

Optical

Optical type
Biaxial (-)
Refractive index
1.978
Surface relief
Very high
Principal indices
nα 1.978 · nγ 2.0`10
Pleochroism
Strong

X = yellowish or brownish and Z = brown black.

Dispersion
dispersion is r > v.
Optical colour
grayish yellow
Anisotropism
weak
Bireflectance
weak
Tropism
Anisotropic
Michel-Lévy diagramhighlighted lineδ = 4.0220
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]40220 nmhigh order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation40220 nm
Orderhigh order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/a
Cell parameters
a = 13.4656(15) Å · b = 5.7356(6) Å · c = 11.0977(12) Å
Cell angles
β = 100.636(2) °
Ratio a:b:c
1 : 0.426 : 0.824
Z
2
Twinning

sometimes observed

Type-locality form

euhedral to subhedral short prismatic or thick tabular crystals.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
58CeCeriumCerium4140.116560.464
26.69%
57LaLanthanumLanthanum4138.905555.620
26.46%
8OOxygenOxygen2215.999351.978
16.76%
26FeIronIron555.845279.225
13.30%
22TiTitaniumTitanium447.867191.468
9.12%
14SiSiliconSilicon428.085112.340
5.35%
12MgMagnesiumMagnesium224.30548.610
2.32%
Total2099.705100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Dingdaohengiet-(Ce)
  • IMA2005-014

In other languages

German
Dingdaohengit-(Ce) · IMA 2005-014
Italian
dingdaohengite-(Ce)
Chinese
丁道衡矿

Classification

Strunz
10th ed.

9.BE.70

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BESi2O7 groups, with additional anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BE.70Dingdaohengite-(Ce)Species
Dana
8th ed.

56.02.13.09

  • 56Sorosilicates Si2o7 Groups, with Additional O, Oh, F and H2oClass
  • 56.02Si2O7 Groups and O, OH, F, and H2O with cations in [4] and/or >[4] coordinationType
  • 56.02.13— unnamed intermediate level —Group
  • 56.02.13.09Dingdaohengite-(Ce)Species

Group, growth & confusion

Literature, links & citation

Citations
  1. 2005Li, Guo-wu, Yang, Guang-ming, Ma, Zhe-sheng, Shi, Ni-cheng, Xiong, Ming, Sheng, Gan-fu and Fan, Hai-fu (2005) The crystal structure of a new mineral Dingdaohengite-(Ce). Kuangwu Xuebao: 25: 313-320 (in Mandarin).
  2. 2008Xu, J., Yang, G. G, Li, G., Wu, Z., Shen, G. (2008) Dingdaohengite-(Ce) from the Bayan Obo REE-Nb-Fe Mine, China: Both a true polymorph of perrierite-(Ce) and a titanic analog at the C1 site of chevkinite subgroup. American Mineralogist, 93 (5) 740-744 doi:10.2138/am.2008.2543DOI: 10.2138/am.2008.2543
  3. 2021(2021) Dingdaohengite-(Ce). Handbook of Mineralogy. Mineralogical Society of America
