Chlorellestadite

Ca10(SiO4)3(SO4)3Cl2
IMA status
  • Approved
IMA symbol
Clel
Discovered
1982
IMA approved
2017
Also known as
  • Chlorellestadiet
  • Chlorellestadita
  • IMA2017-013

Where it forms, where it's found

Geological setting

Calcium-silicate xenolith in rhyodacite lava

Type locality
NW slope
  1. Shadil-Khokh volcano
  2. Kel’ volcanic area
  3. South Ossetia
  4. Georgia

42.5425°, 44.2975°

5recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
White · tinged with blue or green
Streak
white
Tenacity
brittle
Cleavage
Poor/Indistinct

Parallel to elongation

Fracture
Irregular/Uneven
Density
3.091 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.659 – 1.664
Surface relief
High
Principal indices
nω 1.664 · nε 1.659
Birefringence
0.005
Pleochroism
Non-pleochroic
Extinction
Parallel
UV response
None
Michel-Lévy diagramhighlighted lineδ = 0.0050
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]50 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation50 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
#108
Cell parameters
a = 9.6002(2) Å · c = 6.8692(2) Å
Unit cell volume
548.27 ų
Z
2
Morphology

Elongate crystals

Type-locality form

Inhomogeneous, porous, elongate grains up to 0.2-0.3 mm in length

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
20CaCalciumCalcium1040.078400.780
38.68%
8OOxygenOxygen2415.999383.976
37.06%
16SSulfurSulfur332.06096.180
9.28%
14SiSiliconSilicon328.08584.255
8.13%
17ClChlorineChlorine235.45070.900
6.85%
Total1036.091100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Fe
  • Mn
  • Mg
  • C

Synonyms

  • Chlorellestadiet
  • Chlorellestadita
  • IMA2017-013

In other languages

German
Chlorellestadit · IMA 2017-013
Italian
Clorellestadite · ellestadite-(Cl)
Chinese
氯硅磷灰石

Classification

Strunz
10th ed.

9.AH.25

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AHNesosilicates with CO3, SO4, PO4, etc.Group
  • 9.AH.25ChlorellestaditeSpecies
Dana
8th ed.

52.04.09.05

  • 52Nesosilicates Insular Sio4 Groups and O, Oh, F, H2oClass
  • 52.04Insular SiO4 Groups and O, OH, F, and H2O with cations in [6] and/or >[6] coordinationType
  • 52.04.09Silicate apatitesGroup
  • 52.04.09.05ChlorellestaditeSpecies
CIM

17.10.20

  • 17Silicates Containing other AnionsClass
  • 17.10Silicates with sulphate, molybdate or tungstateGroup
  • 17.10.20ChlorellestaditeSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 1982Rouse, R.C., Dunn, P.J. (1982) A contribution to the crystal chemistry of ellestadite and silicate sulfate apatites. American Mineralogist: 67: 90-96.
  2. 2005Jegou Saint-Jean, S., Hansen, S. (2005) Nonstoichiometry in chlorellestadite. Solid State Sciences: 7: 97-102.
  3. 2010Pasero, Marco, Kampf, Anthony R., Ferraris, Cristiano, Pekov, Igor V., Rakovan, John, White, Timothy J. (2010) Nomenclature of the apatite supergroup minerals. European Journal of Mineralogy, 22 (2) 163-179 doi:10.1127/0935-1221/2010/0022-2022DOI: 10.1127/0935-1221/2010/0022-2022
  4. 2017Hålenius, U., Hatert, F., Pasero, M., Mills, S. J. (2017) New minerals and nomenclature modifications approved in 2017, CNMNC Newsletter No 37. Mineralogical Magazine, 81 (3) 737-742 doi:10.1180/minmag.2017.081.039DOI: 10.1180/minmag.2017.081.039
  5. 2018Środek, Dorota, Galuskina, Irina O., Galuskin, Evgeny, Dulski, Mateusz, Książek, Maria, Kusz, Joachim, Gazeev, Viktor (2018) Chlorellestadite, Ca5(SiO4)1.5(SO4)1.5Cl, a new ellestadite- group mineral from the Shadil-Khokh volcano, South Ossetia. Mineralogy and Petrology, 112 (5) 743-752 doi:10.1007/s00710-018-0571-1DOI: 10.1007/s00710-018-0571-1
