Hydroxylellestadite

Ca5(SiO4)1.5(SO4)1.5OH
IMA status
  • Approved
  • Grandfathered
IMA symbol
Hel
Discovered
1971
Also known as
  • Ellestadite-(OH)
  • Hydroxylellestadiet
  • Hydroxylellestadita
  • +1 more

Where it forms, where it's found

Type locality
Chichibu mining district
  1. Nakatsugawa
  2. Ohtaki-mura
  3. Chichibu City
  4. Saitama Prefecture
  5. Japan

36.0222°, 138.8167°

21recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Light orange · Pink · Purple-grey
Tenacity
brittle
Cleavage
Poor/Indistinct
Fracture
Irregular/Uneven
Density
3.068 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.65 – 1.654
Surface relief
High
Principal indices
nω 1.654 · nε 1.650
Michel-Lévy diagramhighlighted lineδ = 0.0040
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]40 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation40 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
P63/m 2/c 2/m
Cell parameters
a = 9.491 Å · c = 6.921 Å
Z
2
Morphology

Anhedral masses.

Type-locality form

Anhedral, cleavable aggregates up to 100 kg. Individual cleavage pieces are up to 2 cm along the c axis

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1315.999207.987
41.63%
20CaCalciumCalcium540.078200.390
40.11%
16SSulfurSulfur1.532.06048.090
9.63%
14SiSiliconSilicon1.528.08542.127
8.43%
1HHydrogenHydrogen11.0081.008
0.20%
Total499.603100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Fe
  • Mn
  • Mg
  • Sr
  • Na
  • K
  • P
  • C

Synonyms

  • Ellestadite-(OH)
  • Hydroxylellestadiet
  • Hydroxylellestadita
  • IMA1970-026

In other languages

German
Ellestadit-(OH) · Hydroxylellestadit · IMA 1970-026
Italian
Hydroxylellestadite · Idrossilellestadite
Japanese
水酸エレスタド石
Chinese
羟硅磷灰石

Classification

Strunz
10th ed.

9.AH.25

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AHNesosilicates with CO3, SO4, PO4, etc.Group
  • 9.AH.25HydroxylellestaditeSpecies
Dana
8th ed.

52.04.09.04

  • 52Nesosilicates Insular Sio4 Groups and O, Oh, F, H2oClass
  • 52.04Insular SiO4 Groups and O, OH, F, and H2O with cations in [6] and/or >[6] coordinationType
  • 52.04.09Silicate apatitesGroup
  • 52.04.09.04HydroxylellestaditeSpecies
CIM

17.10.21

  • 17Silicates Containing other AnionsClass
  • 17.10Silicates with sulphate, molybdate or tungstateGroup
  • 17.10.21HydroxylellestaditeSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 1971Harada, Kazuo, Nagashima, Kozo, Nakao, Kazuso, Kato, and Akira (1971) Hydroxylellestadite, a new apatite from Chichibu mine, Saitama Prefecture, Japan. American Mineralogist, 56 (9-10) 1507-1518
  2. 1980Sudarsanan, K. (1980) Structure of hydroxyellestadite. Acta Crystallographica Section B Structural Crystallography and Crystal Chemistry, 36 (7) 1636-1639 doi:10.1107/s0567740880006759DOI: 10.1107/s0567740880006759
  3. 1982Rouse, R.C., Dunn, P.J. (1982) A contribution to the crystal chemistry of ellestadite and silicate sulfate apatites. American Mineralogist: 67: 90-96.
  4. 1991Neues Jahrbuch für Mineralogie, Monatshefte (1991): 327.
  5. 2006Onac, B. P., Effenberger, H., Ettinger, K., Panzaru, S. C. (2006) Hydroxylellestadite from Cioclovina Cave (Romania): Microanalytical, structural, and vibrational spectroscopy data. American Mineralogist, 91 (11) 1927-1931 doi:10.2138/am.2006.2143 DOI: 10.2138/am.2006.2143
