Cobaltkoritnigite

Co(AsO3OH) · H2O
IMA status
  • Approved
IMA symbol
Ckor
Discovered
1980
IMA approved
1980
Also known as
  • Cobaltkoritnigiet
  • IMA1980-013
  • Kobaltkoritnigit

Where it forms, where it's found

Geological setting

Oxidized cobalt ore, post-mining.

Type locality
Schwarzenberg mining district
  1. Erzgebirgskreis
  2. Saxony
  3. Germany
28recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent · Translucent
Colour
Pale purple to intense purple · pale rose red to intense purple-rose
Streak
Pale pink
Tenacity
brittle
Cleavage
Perfect

(010) perfect; (100) good.

Density
3.44 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 78° · 2V calc = 78°
Refractive index
1.646 – 1.705
Surface relief
High
Principal indices
nα 1.646 · nβ 1.668 · nγ 1.705
Birefringence
0.059
Pleochroism
Strong

X = deep violet; Y = reddish violet; Z = bluish violet.

Dispersion
weak
Extinction
X ∧ b = 3°, Y ∧ a = 12.5°.
UV response
Not fluorescent
Michel-Lévy diagramhighlighted lineδ = 0.0590
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]590 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation590 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
P-1
Cell parameters
a = 7.95 Å · b = 15.83 Å · c = 6.67 Å
Cell angles
α = 90.9 ° · β = 96.6 ° · γ = 90.0 °
Ratio a:b:c
1 : 1.991 : 0.839
Z
8
Type-locality form

Intensely colored purple tabular crystals.

Comment

NJMM 257 (1981)

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen515.99979.995
36.89%
33AsArsenicArsenic174.92274.922
34.55%
27CoCobaltCobalt158.93358.933
27.17%
1HHydrogenHydrogen31.0083.024
1.39%
Total216.874100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Cobaltkoritnigiet
  • IMA1980-013
  • Kobaltkoritnigit

In other languages

German
Cobaltkoritnigit · IMA 1980-013 · Kobaltkoritnigit
Italian
Cobaltkoritnigite · Cobaltokoritnigite

Classification

Strunz
10th ed.

8.CB.20

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CBWith only medium-sized cations, RO4:H2O = 1:1Group
  • 8.CB.20CobaltkoritnigiteSpecies
Dana
8th ed.

39.01.04.02

  • 39Hydrated Acid Phosphates, Arsenates and VanadatesClass
  • 39.01A[HXO4]·xH2OType
  • 39.01.04— unnamed intermediate level —Group
  • 39.01.04.02CobaltkoritnigiteSpecies
CIM

20.10.6

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.10Arsenates of Co and NiGroup
  • 20.10.6CobaltkoritnigiteSpecies

Group, growth & confusion

In the same group
2 members
Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1979Zettler, V.F., Riffel, H., Hess, H. and Keller, P. (1979) Cobalthydrogenarsenat-monohydrat. Darstellung und Kristallstruktur. Zeitschrift für anorganische und allgemeine Chemie, 454, 134-144.
  2. 1980Neues Jahrbuch für Mineralogie (1980) Monatshefte, 237.
  3. 1981Schmetzer, K., Horn, W., Medenbach, O. (1981) Über Kobaltkoritnigit, (Co,Zn)[H2O/AsO3OH], ein neues Mineral und Pitticit, Fe2O3·As2O5·9-10 H2O, ein röntgenamorphes Fe-Arsenat-Hydrat [On cobaltkoritnigite, (Co,Zn)[H2O/AsO3OH], a new mineral, and pitticite, Fe2O3·As2O5·9-10 H2O, an amorphous Fe-arsenate-hydrate]. Neues Jahrbuch für Mineralogie - Monatshefte, 1981. 257-266
  4. 1982Fleischer, M., Burns, R.G., Cabri, L.J., Francis, C.A., Pabst, A. (1982) New mineral names. American Mineralogist, 67, 413-418.
  5. 2005(2005) Cobaltkoritnigite. Handbook of Mineralogy. Mineralogical Society of America
