Columbite-(Mn)

Mn2+Nb2O6
IMA status
  • Approved
  • Grandfathered
IMA symbol
Clb-Mn
Discovered
1892
Also known as
  • Columbiet-(Mn)
  • Manganocolumbit
  • Manganocolumbita
  • +4 more

Where it forms, where it's found

307recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent · Opaque
Colour
Black to brownish black · dark red-brown · reddish brown in transmitted light
Streak
Dark red to black
Tenacity
brittle
Cleavage
Distinct/Good

Distinct on (100), less distinct on (010).

Fracture
Irregular/Uneven · Sub-Conchoidal
Density
5.20 g/cm³

Optical

Optical type
Biaxial (-)
Dispersion
r > v strong
Extinction
Parallel. X = b; Y = a; Z = c.
Notes

Absorption: Strong. Z > X.

Crystallography

Crystal system
Orthorhombic
Space group
#63
Cell parameters
a = 14.433(2) Å · b = 5.7637(7) Å · c = 5.0832(8) Å
Ratio a:b:c
1 : 0.399 : 0.352
Z
4
Morphology

Crystals short prismatic or equant, also tabular; in groups of parallel or subparallel crystals; massive.

Twinning

On (021) and (023), may produce pseudohexagonal trillings.

Comment

Synthetic material. Strong subcell has b/3.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
41NbNiobiumNiobium292.906185.812
55.18%
8OOxygenOxygen615.99995.994
28.51%
25MnManganeseManganese154.93854.938
16.31%
Total336.744100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Columbiet-(Mn)
  • Manganocolumbit
  • Manganocolumbita
  • Manganocolumbite
  • Manganotantalocolumbit
  • Manganotantalocolumbita
  • Manganotantalocolumbite

In other languages

German
Columbit-(Mn)
Spanish
Columbita- · Columbita-(Mn)
Italian
Columbite- · columbite-(Mn) · Manganocolumbite
Chinese
铌锰矿

Classification

Strunz
10th ed.

4.DB.35

  • 4OxidesClass
  • 4.DMetal: Oxygen = 1:2 and similarDivision
  • 4.DBWith medium-sized cations; chains of edge-sharing octahedraGroup
  • 4.DB.35Columbite-(Mn)Species
Dana
8th ed.

08.03.02.04

  • 08Multiple Oxides Containing Niobium, Tantalum or TitaniumClass
  • 08.03AB2O6Type
  • 08.03.02Tantalite - Columbite SeriesGroup
  • 08.03.02.04Columbite-(Mn)Species
CIM

18.1.39

  • 18Niobates and TantalatesClass
  • 18.1Niobates and tantalates containing neither rare earths nor UGroup
  • 18.1.39Columbite-(Mn)Species

Group, growth & confusion

In the same group
6 members
Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1892Dana, Edward Salisbury; Dana, James Dwight (1892) A System of Mineralogy (6th ed.). John Wiley & Sons, Inc.
  2. 1995Ercit, T. Scott, Wise, Michael A., Cerny, Petr (1995) Compositional and structural systematics of the columbite group. American Mineralogist, 80 (5) 613-619 doi:10.2138/am-1995-5-619 DOI: 10.2138/am-1995-5-619
  3. 2005(2005) Columbite-(Mn). Handbook of Mineralogy. Mineralogical Society of America
  4. 2008Burke, Ernst A. J. (2008) Tidying up mineral names: an IMA-CNMNC scheme for suffixes, hyphens and diacritical marks. The Mineralogical Record, 39 (2) 131-135
  5. 2011Kinast, E. J., Isnard, O., da Cunha, J. B. M., de Vasconcellos, M. A. Z., dos Santos, C. A. (2011) A new approach for the determination of multiple cation locations and ordering, using the example of natural and heat-treated columbites. Journal of Applied Crystallography, 44 (4). 738-746 doi:10.1107/s0021889811023211DOI: 10.1107/s0021889811023211
