Tantalite-(Mn)

Mn2+Ta2O6
IMA status
  • Approved
  • Grandfathered
IMA symbol
Ttl-Mn
Discovered
1887
Also known as
  • Alvarolit
  • Alvarolita
  • Alvarolite
  • +4 more

Where it forms, where it's found

Geological setting

Accessory mineral in granitic pegmatites.

Type locality
Utö Mines
  1. Utö
  2. Haninge
  3. Stockholm County
  4. Sweden

58.9661°, 18.3297°

216recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Pink to nearly colourless · reddish brown to black
Streak
Red, scarlet to black
Tenacity
brittle
Cleavage
Distinct/Good

Distinct on (100) Less distinct (010)

Fracture
Irregular/Uneven · Sub-Conchoidal
Density
6.65 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
2.14 – 2.34
Surface relief
Very high
Principal indices
nα 2.14 · nβ 2.15 · nγ 2.34
Pleochroism
Strong

Red, red-brown, orange

Dispersion
r < v strong
Extinction
Parallel. X = a; Y = b; Z = c.
Tropism
Anisotropic
Reflectance R%
(15.5,16.4) 400, (15.1,16.0) 420, (14.8,15.7) 440, (14.6,15.4) 460, (14.3,15.2) 480, (14.1,15.0) 500, (13.9,14.8) 520, (13.8,14.7) 540, (13.6,14.5) 560, (13.6,14.4) 580, (13.5,14.4) 600, (13.5,14.3) 620, (13.4,14.3) 640, (13.4,14.3) 660, (13.3,14.2) 680, (13.3,14.2) 700
Notes

Absorption: Strong. Z > X.

Reflected-light panel
14.0 %anisotropic · dual curve
Specimen sRGB 138, 96, 53
White reference100 % reflector under same lamp
R₁ R₂
Mode

Crystallography

Crystal system
Orthorhombic
Space group
#63
Cell parameters
a = 14.44 Å · b = 5.7661(8) Å · c = 5.093 Å
Ratio a:b:c
1 : 0.399 : 0.353
Z
4
Morphology

Short prismatic to tabular.

Twinning

On (021), (023). Pseudohexagonal trillings.

Comment

On synthetic material

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
73TaTantalumTantalum2180.948361.896
70.57%
8OOxygenOxygen615.99995.994
18.72%
25MnManganeseManganese154.93854.938
10.71%
Total512.828100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Nb

Synonyms

  • Alvarolit
  • Alvarolita
  • Alvarolite
  • Manganotantalit
  • Manganotantalite
  • Mangantantalite
  • Tantaliet-(Mn)

In other languages

German
Tantalit- · Tantalit-(Mn)
Spanish
Tantalita- · Tantalita-(Mn)
Italian
Manganotantalite · Tantalite- · tantalite-(Mn)
Russian
Манганотанталит

Classification

Strunz
10th ed.

4.DB.35

  • 4OxidesClass
  • 4.DMetal: Oxygen = 1:2 and similarDivision
  • 4.DBWith medium-sized cations; chains of edge-sharing octahedraGroup
  • 4.DB.35Tantalite-(Mn)Species
Dana
8th ed.

08.03.02.03

  • 08Multiple Oxides Containing Niobium, Tantalum or TitaniumClass
  • 08.03AB2O6Type
  • 08.03.02Tantalite - Columbite SeriesGroup
  • 08.03.02.03Tantalite-(Mn)Species
CIM

18.1.36

  • 18Niobates and TantalatesClass
  • 18.1Niobates and tantalates containing neither rare earths nor UGroup
  • 18.1.36Tantalite-(Mn)Species

Group, growth & confusion

In the same group
6 members
Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1887Arzruni (1887), Russ. Ges. Min., Vh.: 23: 181.
  2. 1944Palache, Charles, Berman, Harry, Frondel, Clifford (1944) The System of Mineralogy (7th ed.) Vol. 1 - Elements, Sulfides, Sulfosalts, Oxides. John Wiley and Sons, New York.
  3. 1976Grice, J. D., Ferguson, R. B., Hawthorne, F. C. (1976) The crystal structures of tantalite, ixiolite and wodginite from Bernic lake, Manitoba. I. Tantalite and ixiolite. The Canadian Mineralogist, 14 (4) 540-549
  4. 1980Sahama, T.G. (1980) Minerals of the tantalite-niobite series from Mozambique. Bulletin de Minéralogie, 103, 190-197.
  5. 1985Wise, M.A., A.C. Turnock, and P. Černý (1985) Improved unit cell dimensions for ordered columbite-tantalite end members. Neues Jahrbuch für Mineralogie - Monatshefte, 372-378.
