Tantalite-(Fe)

Fe2+Ta2O6
IMA status
  • Approved
IMA symbol
Ttl-Fe
Discovered
1836
Also known as
  • Ferrotantalit
  • Ferrotantalite
  • Siderotantal
  • +1 more

Where it forms, where it's found

Geological setting

As a very accessory mineral in granitic pegmatites. Most tantalites with this composition are actually tapiolite structure.

Type locality
Upper Bear Gulch
  1. Tinton Pegmatite Mining District
  2. Lawrence County
  3. South Dakota
  4. USA
108recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106 – 6.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Iron-black

Reddish brown in transmitted light.

Streak
Black, dark reddish-brown.
Tenacity
brittle
Cleavage
Distinct/Good

Distinct on (100), less distinct on (010)

Fracture
Irregular/Uneven · Splintery · Sub-Conchoidal
Density
6.65 g/cm³

Optical

Optical type
Biaxial (-)
Refractive index
2.26 – 2.43
Surface relief
Very high
Principal indices
nα 2.26 · nβ 2.3 – 2.4 · nγ 2.43
Dispersion
Relatively strong, r < v.
Extinction
X = b; Y = a; Z = c.
Optical colour
Grey
Internal reflections
Red to reddish brown.
Notes

Absorption: Strong. Z > X.

Michel-Lévy diagramhighlighted lineδ = 0.1700
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1700 nm4th order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1700 nm
Order4th order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#63
Cell parameters
a = 5.73 Å · b = 14.24 Å · c = 5.08 Å
Ratio a:b:c
1 : 2.485 : 0.887
Morphology

Exsolution intergrowths with ferrotapiolite.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
73TaTantalumTantalum2180.948361.896
70.44%
8OOxygenOxygen615.99995.994
18.69%
26FeIronIron155.84555.845
10.87%
Total513.735100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Ferrotantalit
  • Ferrotantalite
  • Siderotantal
  • Tantaliet-(Fe)

In other languages

German
Tantalit-(Fe)
Spanish
Tantalita- · Tantalita-(Fe)
Italian
Tantalite- · tantalite-(Fe)

Classification

Strunz
10th ed.

4.DB.35

  • 4OxidesClass
  • 4.DMetal: Oxygen = 1:2 and similarDivision
  • 4.DBWith medium-sized cations; chains of edge-sharing octahedraGroup
  • 4.DB.35Tantalite-(Fe)Species
Dana
8th ed.

08.03.02.01

  • 08Multiple Oxides Containing Niobium, Tantalum or TitaniumClass
  • 08.03AB2O6Type
  • 08.03.02Tantalite - Columbite SeriesGroup
  • 08.03.02.01Tantalite-(Fe)Species
CIM

18.1.43

  • 18Niobates and TantalatesClass
  • 18.1Niobates and tantalates containing neither rare earths nor UGroup
  • 18.1.43Tantalite-(Fe)Species

Group, growth & confusion

In the same group
6 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1836Thomson, T. (1836) On the minerals containing columbium. Records of General Science: 4: 407-419 (416-419).
  2. 1944Palache, Charles, Berman, Harry, Frondel, Clifford (1944) The System of Mineralogy (7th ed.) Vol. 1 - Elements, Sulfides, Sulfosalts, Oxides. John Wiley and Sons, New York.
  3. 1966Turnock, A. C. (1966) Synthetic wodginite, tapiolite and tantalite. The Canadian Mineralogist, 8 (4) 461-470
  4. 1975American Mineralogist: (1975): 60: 613.
  5. 1995Ercit, T. Scott, Wise, Michael A., Cerny, Petr (1995) Compositional and structural systematics of the columbite group. American Mineralogist, 80 (5) 613-619 doi:10.2138/am-1995-5-619 DOI: 10.2138/am-1995-5-619
