Coquimbite

AlFe3(SO4)6(H2O)12 · 6H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Coq
Discovered
1841
Also known as
  • Blakeite (of Dana)
  • Neutrales schwefelsaures Eisenoxyd

Where it forms, where it's found

Geological setting

Secondary weathering zone of iron sulfide deposits in arid regions. Rarely in fumaroles.

Type locality
Coquimbo
  1. Chile
139recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Light violet to purple · Greenish white · Bluish white · Yellowish white · Brownish white
Streak
white
Tenacity
brittle
Cleavage
Imperfect/Fair

fair/imperfect on [10_11] very poor/difficult on (1010)

Fracture
Sub-Conchoidal
Density
2.11 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.539 – 1.548
Surface relief
Moderate
Principal indices
nω 1.539 · nε 1.548
Birefringence
0.009
Pleochroism
Non-pleochroic
Extinction
Parallel
UV response
Not fluorescent in UV
Michel-Lévy diagramhighlighted lineδ = 0.0090
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]90 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation90 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#94
Cell parameters
a = 10.922(9) Å · c = 17.084(14) Å
Z
4
Morphology

Short prismatic [0001] with (1010) and (1120) to pyramidal crystals (1011). Massive, granular.

Epitaxy

Paracoquimbite in parallel position. Lamellar intergrowths on (0001), or as scepter-like overgrowths.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen4215.999671.958
61.36%
16SSulfurSulfur632.060192.360
17.57%
26FeIronIron355.845167.535
15.30%
1HHydrogenHydrogen361.00836.288
3.31%
13AlAluminiumAluminium126.98226.982
2.46%
Total1095.123100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al

Synonyms

  • Blakeite (of Dana)
  • Neutrales schwefelsaures Eisenoxyd

In other languages

French
Coquimbite
German
Coquimbit
Spanish
Coquimbita
Italian
Coquimbite

Classification

Strunz
10th ed.

7.CB.55

  • 7SulfatesClass
  • 7.CSulfates (selenates, etc.) without additional anions, with H2ODivision
  • 7.CBWith only medium-sized cationsGroup
  • 7.CB.55CoquimbiteSpecies
Dana
8th ed.

29.08.03.01

  • 29Hydrated Acid and Normal SulfatesClass
  • 29.08A2(XO4)3·H2OType
  • 29.08.03— unnamed intermediate level —Group
  • 29.08.03.01CoquimbiteSpecies
CIM

25.10.9

  • 25SulphatesClass
  • 25.10Sulphates of Fe aloneGroup
  • 25.10.9CoquimbiteSpecies

Group, growth & confusion

In the same group
2 members
Often grow together
5 minerals

Literature, links & citation

Citations
  1. American Mineralogist: 55: 1534-1540.
  2. 1833Rose (1833) Annalen der Physik, Halle, Leipzig (as Neutrales schwefelsaures Eisenoxyd).
  3. 1841Breithaupt, A. (1841) Vollständige Handbuch der Mineralogie. Vol. 2: 100.
  4. 1879Arzruni (1879) Zeitschrift für Kristallographie, Mineralogie und Petrographie, Leipzig: 3: 516.
  5. 1889Linck (1889) Zeitschrift für Kristallographie, Mineralogie und Petrographie, Leipzig: 15: 7.
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Coquimbite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/coquimbite-1126},
  note      = {Accessed 2026-05-11}
}
