Tamarugite

NaAl(SO4)2 · 6H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Tmr
Discovered
1889

Where it forms, where it's found

Geological setting

Occurs under arid conditions by the oxidation of sulphides in aluminous and alkali-rich environments.

Type locality
Cerros Pintados
  1. Tamarugal Province
  2. Tarapacá
  3. Chile

-20.6294°, -69.6572°

89recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless · colourless in transmitted light.
Streak
White
Cleavage
Perfect

On (010), perfect; not easy.

Density
2.06 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 60° · 2V calc = 48°
Refractive index
1.484 – 1.497
Surface relief
Low
Principal indices
nα 1.484 · nβ 1.486 · nγ 1.497
Dispersion
r > v to r < v strong
Michel-Lévy diagramhighlighted lineδ = 0.0130
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]130 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation130 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/a
Cell parameters
a = 7.353(2) Å · b = 25.225(5) Å · c = 6.097(2) Å
Cell angles
β = 95.2(1) °
Ratio a:b:c
1 : 3.431 : 0.829
Z
4
Morphology

Crystals short tabular (010) or short prismatic [001]. Fibrous or fine-grained massive. A characteristic of the crystals is that the forms all fall in four principal zones (prisms, positive pyramids, positive domes, and negative pyramids), (Gordon 1940). (110), (120), (010) (111), (121), (131), (141), (151), (161) (011), (021), (031), (041) (111), (121), (131), (141)

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
63.96%
16SSulfurSulfur232.06064.120
18.31%
13AlAluminiumAluminium126.98226.982
7.71%
11NaSodiumSodium122.99022.990
6.57%
1HHydrogenHydrogen121.00812.096
3.45%
Total350.174100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

In other languages

German
Tamarugit
Spanish
Tamarugita
Italian
Tamarugite

Classification

Strunz
10th ed.

7.CC.10

  • 7SulfatesClass
  • 7.CSulfates (selenates, etc.) without additional anions, with H2ODivision
  • 7.CCWith medium-sized and large cationsGroup
  • 7.CC.10TamarugiteSpecies
Dana
8th ed.

29.05.03.01

  • 29Hydrated Acid and Normal SulfatesClass
  • 29.05AB(XO4)2·xH2OType
  • 29.05.03— unnamed intermediate level —Group
  • 29.05.03.01TamarugiteSpecies
CIM

25.6.12

  • 25SulphatesClass
  • 25.6Sulphates of Al and TlGroup
  • 25.6.12TamarugiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1870Cleve, P.T. (1870) On the Geology of North-Eastern West India Islands. Kungliga Svenska vetenskapsakademiens handlingar. Ny följd [New Series], 9 (6-15). 1-48
  2. 1889Schulze, H. (1889) Mineralogisches aus Tarapacá. Verhandlungen des Deutschen Wissenschaftlichen Vereines zu Santiago: 2: 49-60 (56).
  3. 1892Domeyko, I. (1892) Mineralojia, 2nd Appendix to 3rd ed.: 30. (as alumbre nativo (native alum))
  4. 1907Zambonini, F. (1907) Su Alunci Minerali dell Grotto a Miseno. Rendiconto dell'Accademia delle Scienze Napoli: 46: 321-331.
  5. 1935Ungemach, Henri (1935) Sur certains minéraux sulfatés du Chili. Bulletin de Minéralogie, 58 (3) 97-221 doi:10.3406/bulmi.1935.4369DOI: 10.3406/bulmi.1935.4369
