Crichtonite

Sr(Mn,Y,U)Fe2(Ti,Fe,Cr,V)18(O,OH)38
IMA status
  • Approved
  • Grandfathered
IMA symbol
Cic
Discovered
1813
Also known as
  • Crichtoniet

Where it forms, where it's found

Type locality
Saint-Christophe-en-Oisans
  1. Grenoble
  2. Isère
  3. Auvergne-Rhône-Alpes
  4. France
29recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789105 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Black
Streak
Dark grey
Density
4.46 g/cm³

Crystallography

Crystal system
Trigonal
Space group
#80
Cell parameters
a = 10.37 Å · c = 20.74 Å
Z
3
Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen7615.9991215.924
21.89%
26FeIronIron2055.8451116.900
20.10%
24CrChromiumChromium1851.996935.928
16.85%
23VVanadiumVanadium1850.942916.956
16.51%
22TiTitaniumTitanium1847.867861.606
15.51%
92UUraniumUranium1238.029238.029
4.28%
39YYttriumYttrium188.90688.906
1.60%
38SrStrontiumStrontium187.62087.620
1.58%
25MnManganeseManganese154.93854.938
0.99%
1HHydrogenHydrogen381.00838.304
0.69%
Total5555.111100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Crichtoniet

In other languages

French
Groupe de la crichtonite
German
Crichtonit
Spanish
Crichtonita
Italian
Crichtonite
Chinese
锶铁钛矿

Classification

Strunz
10th ed.

4.CC.40

  • 4OxidesClass
  • 4.CMetal: Oxygen = 2: 3,3: 5, and similarDivision
  • 4.CCWith large and medium-sized cationsGroup
  • 4.CC.40CrichtoniteSpecies
Dana
8th ed.

08.05.01.03

  • 08Multiple Oxides Containing Niobium, Tantalum or TitaniumClass
  • 08.05AB21O38Type
  • 08.05.01Crichtonite group (ABC18 T2 O38)Group
  • 08.05.01.03CrichtoniteSpecies
CIM

7.9.9

  • 7Oxides and HydroxidesClass
  • 7.9Oxides of TiGroup
  • 7.9.9CrichtoniteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1813de Bournon, J.L. (1813): 430.
  2. 1814de Bournon, J.L. (1814) Catalogue de la Collection Minéralogique du Comte de Bournon. The Monthly Review: 73: 17-32.
  3. 1953Claringbull, G.F. (1953) Mineralogical Society (London). American Mineralogist: 38: 734-737.
  4. 1969Ramdohr, Paul (1969) The Ore Minerals and their Intergrowths. Pergamon Press, Oxford. 1174pp. doi:10.1016/c2013-0-10027-xDOI: 10.1016/c2013-0-10027-x
  5. 1969Hey, M. H., Embrey, P. G., Fejer, E. E. (1969) Crichtonite, a distinct species. Mineralogical Magazine, 37 (287) 349-356 doi:10.1180/minmag.1969.037.287.06 DOI: 10.1180/minmag.1969.037.287.06
