Gramaccioliite-(Y)

(Pb,Sr)(Y,Mn)Fe3+2(Ti,Fe3+)18O38
IMA status
  • Approved
IMA symbol
Gmc-Y
Discovered
1976
IMA approved
2001
Also known as
  • Gramaccioliiet-(Y)
  • IMA2001-034

Where it forms, where it's found

Geological setting

Mineralized clefts in a biotite-rich granite gneiss.

Type locality
Sambuco gramaccioliite site (Sambuco “historical” site)
  1. Sambuco
  2. Cuneo Province
  3. Piedmont
  4. Italy

44.3116°, 7.1066°

19recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Black
Streak
Black
Tenacity
brittle
Cleavage
None Observed
Fracture
Conchoidal
Density
4.66 g/cm³

Optical

Pleochroism
Non-pleochroic

<f>R^1 in oil. R^2 in air.</f>

Optical colour
Black
Anisotropism
Very weak
Bireflectance
Low
Tropism
Anisotropic
Reflectance R%
(19.2,6.7) 470, (17.9,5.9) 546, (17.6,5.7) 589, (17.4,5.8) 650
Reflected-light panel
18.0 %anisotropic · dual curve
Specimen sRGB 155, 109, 61
White reference100 % reflector under same lamp
R₁ R₂
Mode
Bireflectance
Low
Anisotropism
Very weak
Reflected colour
Black

Crystallography

Crystal system
Trigonal
Space group
#80
Cell parameters
a = 10.411(3) Å · c = 20.97(3) Å
Z
3
Morphology

Six-sided tabular crystals (rhombohedral-pseudohexagonal), often with a strongly corroded appearance.

Type-locality form

Six-sided tabular crystals to 8 mm across.

Comment

Cell refined from powder data; single-crystal data gave smaller parameters, a = 10.383, c = 20.882 Å (Orlandi et al., 1994). REE-rich material from Samos island has a = 9.1814(5) Å and α = 68.820(4)° (hexagonal setting: a = 10.377, c = 20.872 Å) (Theye et al., 2010).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
26FeIronIron2055.8451116.900
36.92%
22TiTitaniumTitanium1847.867861.606
28.48%
8OOxygenOxygen3815.999607.962
20.10%
82PbLeadLead1207.200207.200
6.85%
39YYttriumYttrium188.90688.906
2.94%
38SrStrontiumStrontium187.62087.620
2.90%
25MnManganeseManganese154.93854.938
1.81%
Total3025.132100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Gramaccioliiet-(Y)
  • IMA2001-034

In other languages

German
Gramaccioliit-(Y) · IMA 2001-034
Spanish
Gramaccioliíta- · Gramaccioliíta-(Y)
Italian
Gramaccioliite- · gramaccioliite-(Y)

Classification

Strunz
10th ed.

4.CC.40

  • 4OxidesClass
  • 4.CMetal: Oxygen = 2: 3,3: 5, and similarDivision
  • 4.CCWith large and medium-sized cationsGroup
  • 4.CC.40Gramaccioliite-(Y)Species

Group, growth & confusion

Literature, links & citation

Citations
  1. 1981Piccoli, G.C. (1981): Davidite di Pianche di Vinadio (CN). Prima segnalazione. Rivista Mineralogica Italiana, 1981, 19-22.
  2. 2004Orlandi, P. & Piccoli, G.C. (2004): Gramaccioliite-(Y) un nuovo minerale alpino del gruppo della crichtonite. Rivista Mineralogica Italiana, 1/2004, 16-17.
  3. 2004Orlandi, Paolo, Pasero, Marco, Rotiroti, Nicola, Olmi, Filippo, Demartin, Francesco, Moëlo, Yves (2004) Gramaccioliite-(Y), a new mineral of the crichtonite group from Stura Valley, Piedmont, Italy. European Journal of Mineralogy, 16 (1) 171-175 doi:10.1127/0935-1221/2004/0016-0171DOI: 10.1127/0935-1221/2004/0016-0171
  4. 2010Theye, T., Hatert, F., Ockenga, E., Bertoldi, C., Lathe, C. (2010): Gramaccioliite-(Y): paragenesis chemistry, and structure in a new occurrence, Samos Island, Greece. European Journal of Mineralogy, 22, 443-452.
  5. 2015(2015) Gramaccioliite-(Y). Handbook of Mineralogy. Mineralogical Society of America
