Cyrilovite

NaFe3+3(PO4)2(OH)4 · 2H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Cyr
Discovered
1953
Also known as
  • Avelinoit
  • Avelinoita
  • Avelinoite
  • +1 more

Where it forms, where it's found

Geological setting

Pegmatite

Accessory mineral in granitic pegmatites

Type locality
Cyrilov phosphate pegmatite (Cyrillhof)
  1. Cyrilov (Cyrillhof)
  2. Horní Bory
  3. Bory
  4. Žďár nad Sázavou District
  5. Vysočina Region
  6. Czech Republic

49.4139°, 16.0469°

69recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Bright yellow · honey-yellow · orange to brownish yellow · brown
Streak
Yellow
Cleavage
None Observed
Fracture
Conchoidal
Density
3.081 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.769 – 1.805
Surface relief
High
Principal indices
nω 1.802 – 1.805 · nε 1.769 – 1.775
Pleochroism
Weak

O= deep yellow to yellow E= colorless to yellow

Michel-Lévy diagramhighlighted lineδ = 0.0315
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]315 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation315 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
#167
Cell parameters
a = 7.313(2) Å · c = 19.315(3) Å
Z
4
Morphology

Thick tabular crystals, also pyramidal, pseudo-octahedral, radiating botryoidal aggregates or crusts.

Type-locality form

Crystalline crusts on frondellite

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
46.23%
26FeIronIron355.845167.535
34.58%
15PPhosphorusPhosphorus230.97461.948
12.79%
11NaSodiumSodium122.99022.990
4.74%
1HHydrogenHydrogen81.0088.064
1.66%
Total484.523100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Avelinoit
  • Avelinoita
  • Avelinoite
  • Cyriloviet

In other languages

French
Cyrilovite
German
Cyrilovit
Spanish
Cyrilovita
Italian
Cyrilovite

Classification

Strunz
10th ed.

8.DL.10

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DLWith large and medium-sized cations, (OH, etc.):RO4 = 2:1Group
  • 8.DL.10CyriloviteSpecies
Dana
8th ed.

42.07.08.01

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.07(AB)2(XO4)Zq·xH2OType
  • 42.07.08Cyrilovite GroupGroup
  • 42.07.08.01CyriloviteSpecies
CIM

19.14.1

  • 19PhosphatesClass
  • 19.14Phosphates of Fe and other metalsGroup
  • 19.14.1CyriloviteSpecies

Group, growth & confusion

In the same group
3 members
Often grow together
1 mineral
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1953Novotný, M., Stanek, J. (1953) Nový minerál, fosforecnan cyrilovit. (Cyrilovite, a new phosphate mineral). Acta Academiae Scientiarum Naturaliuim Moravo-Silesiacae: 25: 325-336.
  2. 1957Lindberg, Marie Louise (1957) Relationship of the minerals avelinoite, cyrilovite and wardite. American Mineralogist, 42 (3-4) 204-213
  3. 1957Fleischer, M. (1957) New mineral names. American Mineralogist, 42 (7-8) 580-586
  4. 1984Tarte, Pierre, Fransolet, André-Mathieu, Pillard, François (1984) Le spectre infrarouge de la cyrilovite et de la wardite : corrélations entre la structure et la composition chimique. Bulletin de Minéralogie, 107 (6) 745-754 doi:10.3406/bulmi.1984.7816DOI: 10.3406/bulmi.1984.7816
  5. 1987Cozzupoli, D., Grubessi, O., Mottana, A., Zanazzi, P. F. (1987) Cyrilovite from Italy: Structure and crystal chemistry. Mineralogy and Petrology, 37 (1) 1-14 doi:10.1007/bf01163154DOI: 10.1007/bf01163154
