Wardite

NaAl3(PO4)2(OH)4 · 2H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Wd
Discovered
1896
Also known as
  • Soumansite
  • Wardiet

Where it forms, where it's found

Geological setting

Low-temperature phosphatic nodules in sedimentary rocks.

Complex zoned pegmatites.

Type locality
Clay Canyon
  1. Fairfield
  2. Sunshine Mining District
  3. Utah County
  4. Utah
  5. USA

40.2764°, -112.1604°

64recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Opaque
Colour
Colourless · white · lightly coloured blue to green · yellow-green · light yellow · brown · colourless in transmitted light.
Cleavage
Perfect

On (001), perfect.

Density
2.81 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.586 – 1.604
Surface relief
Moderate
Principal indices
nω 1.586 – 1.594 · nε 1.595 – 1.604
Notes

Basal sections of crystals from Montebras, France, are divided into four anomalously biaxial sections with Y = [101], Z = [001], and 2E (+) ranging up to 70°.

Michel-Lévy diagramhighlighted lineδ = 0.0095
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]95 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation95 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
#167
Cell parameters
a = 7.03(1) Å · c = 19.04(1) Å
Z
4
Morphology

Crystals dipyramidal, pseudo-octahedral, exhibiting forms (010), (011), (012), (100), and rarely (001). Commonly striated perpendicular to [001]. Granular aggregates and crusts; subparallel aggregates of coarse fibers; radially-fibrous and concentrically banded spherulites.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
56.29%
13AlAluminiumAluminium326.98280.946
20.34%
15PPhosphorusPhosphorus230.97461.948
15.57%
11NaSodiumSodium122.99022.990
5.78%
1HHydrogenHydrogen81.0088.064
2.02%
Total397.934100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Soumansite
  • Wardiet

In other languages

French
Wardite
German
Wardit
Spanish
Wardita
Italian
Wardite
Chinese
水磷鋁鈉石 · 水磷铝钠石

Classification

Strunz
10th ed.

8.DL.10

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DLWith large and medium-sized cations, (OH, etc.):RO4 = 2:1Group
  • 8.DL.10WarditeSpecies
Dana
8th ed.

42.07.08.02

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.07(AB)2(XO4)Zq·xH2OType
  • 42.07.08Cyrilovite GroupGroup
  • 42.07.08.02WarditeSpecies
CIM

19.8.3

  • 19PhosphatesClass
  • 19.8Phosphates of Al and other metalsGroup
  • 19.8.3WarditeSpecies

Group, growth & confusion

In the same group
3 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1896Davison, J.M. (1896) Wardite: a new hydrous basic phosphate of alumina. American Journal of Science: 152: 154-155.
  2. 1930Larsen, Esper S., Shannon, Earl V. (1930) The minerals of the phosphate nodules from near Fairfield, Utah. American Mineralogist, 15 (8) 307-337
  3. 1937Pough, F.H., Montgomery, A., Over, E., Larsen, E.S., Shannon, E.V. (1937) The morphology of wardite. American Museum of Natural History, American Museum novitates, no. 932.
  4. 1942Larsen, Esper S., 3d, (1942) The mineralogy and paragenesis of the variscite nodules from near Fairfield, Utah, Part 1. American Mineralogist, 27 (4) 281-300
  5. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
