Devitoite

Ba6Fe2+7Fe3+2(Si4O12)2(PO4)2(CO3)O2(OH)4
IMA status
  • Approved
IMA symbol
Dvt
IMA approved
2009
Also known as
  • Devitoiet
  • IMA2009-010

Where it forms, where it's found

Geological setting

very late product of the interaction of fluids with sanbornite-quartz vein. It occurs along cleavage planes of altered gillespite.

Type locality
Esquire No. 8 claim
  1. Big Creek
  2. Big Creek-Rush Creek Mining District
  3. Fresno County
  4. California
  5. USA

36.9167°, -119.2456°

3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Brown
Streak
Cream to pale brown
Tenacity
flexible
Cleavage
Perfect

(001); good on (010)

Fracture
Irregular/Uneven
Density
4.044 g/cm³

Optical

Optical type
Biaxial (+) · 2V calc = 53.6°
Refractive index
1.73 – 1.755
Surface relief
High
Principal indices
nα 1.730 · nβ 1.735 · nγ 1.755
Pleochroism
Visible

brown; Y>>>X>Z.

Extinction
Extinction is approximately parallel to the length of the blades in all orientations.
Michel-Lévy diagramhighlighted lineδ = 0.0250
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]250 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation250 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 5.3437(7) Å · b = 11.6726(16) Å · c = 14.680(2) Å
Cell angles
α = 85.573(4) ° · β = 83.243(4) ° · γ = 76.768(4) °
Ratio a:b:c
1 : 2.184 : 2.747
Unit cell volume
884 ų
Z
1
Morphology

very thin blades in subparallel intergrowths; the blades are flattened on (001); elongated and striated parallel to [100]

Type-locality form

Individual crystals can reach 5 mm in length and 0.3 mm in width, but are generally much smaller, and their thickness rarely exceeds 1 μm, Crystals invariably occur in subparallel intergrowths.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
56BaBariumBarium6137.327823.962
36.06%
8OOxygenOxygen4115.999655.959
28.70%
26FeIronIron955.845502.605
21.99%
14SiSiliconSilicon828.085224.680
9.83%
15PPhosphorusPhosphorus230.97461.948
2.71%
6CCarbonCarbon112.01112.011
0.53%
1HHydrogenHydrogen41.0084.032
0.18%
Total2285.197100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ca
  • Mg
  • Ti
  • Al

Synonyms

  • Devitoiet
  • IMA2009-010

In other languages

German
Devitoit · IMA 2009-010
Italian
devitoite

Classification

Strunz
10th ed.

9.DC.05

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DCInosilicates with branched 2-periodic single chains; Si2O6 + 2SiO3 Si4O12Group
  • 9.DC.05DevitoiteSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 2010Kampf, A. R., Rossman, G. R., Steele, I. M., Pluth, J. J., Dunning, G. E., Walstrom, R. E. (2010) Devitoite, a new heterophyllosilicate with astrophyllite-like layers from eastern Fresno County, California. The Canadian Mineralogist, 48 (1). 29-40 doi:10.3749/canmin.48.1.29DOI: 10.3749/canmin.48.1.29
  2. 2011(2011) Devitoite. Handbook of Mineralogy. Mineralogical Society of America
  3. 2017Sokolova, Elena, Cámara, Fernando, Hawthorne, Frank C., Ciriotti, Marco E. (2017) The astrophyllite supergroup: nomenclature and classification. Mineralogical Magazine, 81 (1) 143-153 doi:10.1180/minmag.2016.080.077DOI: 10.1180/minmag.2016.080.077
