Lobanovite

K2Na(Fe2+4Mg2Na)Ti2(Si4O12)2O2(OH)4
IMA status
  • Approved
IMA symbol
Lbv
Discovered
1959
IMA approved
2015
Also known as
  • Lobanoviet
  • Magnesioastrophyllite
  • Magnesium Astrophyllite
  • +2 more

Where it forms, where it's found

Geological setting

Pegmatitic cavities.

Type locality
Yukspor Mountain
  1. Murmansk Oblast
  2. Russia

67.6731°, 33.8122°

7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Colour
Straw yellow to orange
Streak
White to yellowish-white.
Cleavage
Perfect

Perfect cleavage parallel to (001) and moderate cleavage parallel to (010).

Fracture
None observed
Density
3.161 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 81.5 – 83° · 2V calc = 82°
Refractive index
1.658 – 1.71
Surface relief
High
Principal indices
nα 1.658 · nβ 1.687 · nγ 1.71
Pleochroism
Visible

X = bright yellow; Y = pale yellowish grey; Z = grey.

Dispersion
r < v, strong.
Extinction
Y = b; Z ∧ a = –5 to –6°.
Notes

Absorption: Z < Y < X.

Michel-Lévy diagramhighlighted lineδ = 0.0520
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]520 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation520 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 5.3327(2) Å · b = 23.1535(9) Å · c = 10.3775(4) Å
Cell angles
β = 99.615(1) °
Ratio a:b:c
1 : 4.342 : 1.946
Unit cell volume
1263.3 ų
Z
2
Morphology

Elongated blades.

Twinning

None observed.

Parting
None observed.
Type-locality form

Elongated bladed crystals up to 0.04 mm wide and 0.2 mm long.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3015.999479.970
39.98%
14SiSiliconSilicon828.085224.680
18.71%
26FeIronIron455.845223.380
18.61%
22TiTitaniumTitanium247.86795.734
7.97%
19KPotassiumPotassium239.09878.196
6.51%
12MgMagnesiumMagnesium224.30548.610
4.05%
11NaSodiumSodium222.99045.980
3.83%
1HHydrogenHydrogen41.0084.032
0.34%
Total1200.582100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mn
  • F
  • Ca
  • (Nb, Al, Ba)

Synonyms

  • Lobanoviet
  • Magnesioastrophyllite
  • Magnesium Astrophyllite
  • Magnesiumastrophyllite
  • Monoclinic Astrophyllite

In other languages

German
Lobanovit
Italian
Magnesioastrofillite · Magnesiumastrophyllite

Classification

Strunz
10th ed.

9.DC.05

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DCInosilicates with branched 2-periodic single chains; Si2O6 + 2SiO3 Si4O12Group
  • 9.DC.05LobanoviteSpecies
Dana
8th ed.

69.01.01.07

  • 69Inosilicates Chains with Side Branches or LoopsClass
  • 69.01Chains with Side Branches or Loops with (P=2, and N=4, 2 branches)Type
  • 69.01.01Astrophyllite groupGroup
  • 69.01.01.07LobanoviteSpecies
CIM

14.9.31

  • 14Silicates not Containing AluminumClass
  • 14.9Silicates of TiGroup
  • 14.9.31LobanoviteSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 1959Semenov, E. I. (1959): Lithium micas and hydromicas and other ones in alkaline pegmatites of the Kola peninsula. Proceedings of Fersman Mineralogical Museum, Academy of Science USSR : 9: 107-137 (in Russian).
  2. 1963Peng, C. C. & Ma, C. S. (1963) The discovery of a new type of Si-O chain radical - X-ray analysis of astrophyllite. Scientia Sinica: 12: 272-276 (in Russian).
  3. 1974X-ray Laboratory, Hubei Geologic College (1974) The crystal chemistry of astrophyllite group minerals. Scientica Sinica, 1, 18–33 (in Chinese).
  4. 1975Fleischer, Michael, Chao, G. Y., Cabri, L. J. (1975) New mineral names. American Mineralogist, 60 (7-8) 736-739
  5. 1998Pekov, Igor V. (1998) Minerals first discovered on the territory of the former Soviet Union. Ocean Pictures, Moscow. 369pp.
